Netgear Point d´accès WIFI Uplinks

EU Plug.

The XS505M and XS508M come with copper Ethernet 5-speed ports that provide either FastEthernet, 1-Gigabit, 2.5-Gigabit, 5-Gigabit or 10-Gigabit connectivity, as well as 1 SFP+ Fiber port with 1-Gigabit or 10-Gigabit connectivity.

Each port automatically detects which speed is needed by the connected device and provides the adequate speed.

As opposed to regular 10-Gigabit switches that will only provide 1-Gigabit connectivity to any device that require less than 10-Gigabit, the XS505M or XS508M give the exact speed required, no downgrade.

Also, the new NETGEAR 5-speed switch ports can be connected with regular Cat5E Ethernet cables, without the need to upgrade to Cat6 wiring, therefore reducing wiring costs and hassle.

Specifications:

Management.

Features:

- Switch type:Unmanaged.

Ports & interfaces:- Basic switching RJ-45 Ethernet ports quantity:10.

- Basic switching RJ-45 Ethernet ports type:10G Ethernet (100/1000/10000).

- Gigabit Ethernet (copper) ports quantity:8.

- Console port:RJ-45.

- Power connector:DC-in jack.

Network:- Networking standards:IEEE 802.1p,IEEE 802.3x.

- 10G support:Yes Data transmission:- Switching capacity:56 Gbit/s.

- MAC address table:16000 entries.

- Number of trunks:8.

- Packet forwarding rate (1 Gbps):4 pps.

- Packet forwarding rate (100 Mbps):7 pps Design:- LED indicators:Yes.

- Safety:UL 60950-1/CAN/CSA C22.2 No.

60960-1-07 EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013 AS/NZS 60950.1:2015.

Certification:47 CFR FCC, ICES-003:2016, ANSI C63.4:2014, EN 55032:2012 +AC:2013, CISPR 32:2012, AS/NZS CISPR 32:2013, EN 55032:2015 +AC:2016, CISPR 32:2015 +COR1:2016, AS/NZS CISPR 32:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010 +A1:2015, AS/NZS CISPR 32:2015, VCCI-CISPR 32:2016,.

Power:- DC input voltage:13.2 V.

- Power consumption (typical):4.8 W.

- Power consumption (max):6.6 W Power over Ethernet (PoE):- Power over Ethernet (PoE):No Operational conditions:- Operating temperature (T-T):0.

- 40 °C.

- Storage temperature (T-T):-20.

- 70 °C.

- Operating relative humidity (H-H):0.

- 90%.

- Storage relative humidity (H-H):0.

- 95%.

- Operating altitude:0.

- 3000 m.

- Heat dissipation:45.14 BTU/h.

Weight & dimensions:- Width:236 mm.

- Depth:102 mm.

- Height:27 mm.

- Weight:740 g.
