Metabo KGSV 216 M Miter Saw

Features:

- Speed control for extended range of application, e.g. for cutting of aluminium profiles and plastics
- With saw blade ´´multi cut´´ (flat/trapezoidal tooth) for high cutting quality and long service life e.g. in laminate and aluminium profiles
- Large cutting capacity thanks to sliding function for wide work pieces
- Compact light weight, suitable also for one-handed transport
- Robust die-cast aluminium design for the highest demands
- Easy transport thanks to ergonomically-designed handles and saw head lock
- Effective dust extraction via integrated dust scoop
- Vario-Constamatic (VC)-Full wave electronics for working at customised speeds to suit the application materials, and speeds that remain almost constant even under load
- Fast and precise setting of common angles using stop points
- Laser for exact display of the cutting line (mains powered, no batteries required)
- Extendable table width extensions, also removable to put underneath extremely long work pieces
- Bright LED work light for illumination of the cutting line (mains powered, no batteries required)
- Sliding high rear fence profiles for safe sawing
- Quick-action clamp for secure fixing of the work piece from the top or front
- Depth guide for easy creation of grooves
- Saw head can be inclined to the left, with additional angle range for undercuts
- All scales and operating elements are visible from the working position and can be operated intuitively


Specifications:

Characteristics:
- Dimensions: 760 x 475 x 340 mm // 2.5 x 1.6 x 1.1 ft
- Support surface: 345 x 730 mm
- Maximum cutting width 90°/45°: 305 / 205 mm // 12 / 8 1/16 ´´
- Maximum cutting depth at 90°/45°: 65 / 36 mm // 2 9/16 / 1 13/32 ´´
- Cutting capacity 90°/90°: 305 x 65 mm // 12 x 2 1/2 ´´
- Cutting capacity 45°/45°: 205 x 36 mm // 8 1/16 x 1 13/32 ´´
- Turntable setting left/right: 47 / 47 °
- Saw blade tilt left/right: 47 / 2 °
- Saw blade: 216 x 30 mm // 8 1/2 x 1.181 ´´
- Rated input power S1 100%: 1350 W
- Rated input power S6 20%: 1700 W
- No-load speed: 2500 - 5500 rpm
- Revolutions at rated load: 5500 rpm
- Cutting speed: 28 - 62 m/s // 92 - 203 ft/s
- Weight: 13.5 kg / 29.8 lbs
- Cable length: 2 m / 7 ft

Noise emission:
- Sound pressure level: 97 dB(A)
- Sound power level (LwA): 104 dB(A)
- Uncertainty of measurement K: 3 dB(A)
