Fujitsu SCANSNAP-IX1400 Document Scanner

EU Plug.

The fi-7180 provides unmatched performance and market-leading document imaging capabilities.

Even with its compact size, the device scans A4 portrait documents at 80 ppm/160 ipm (200/300 dpi), and is capable of loading up to 80 sheets at a time and scanning up to as many as 11,000 sheets a day.

- Skew Reducer to ensure stable feeding.

- Paper Protection function to protect documents from damage.

- Ultrasonic multi-feed detection for security against lost images.

- Backlit LCD for easy operation viewing.

- Comes with PaperStream IP and PaperStream Capture providing advanced image processing functions.

- Comes with 2D Barcode for PaperStream.

- PaperStream Capture Pro available as an option Feature:Safe and reliable scanning for a seamless workflow:- The fi-7180 provides stable paper feeding mechanisms, and ensures speedy and high quality scanning without relying on PC performance.

Prevent multi-feed errors with reliable feeding functions:- With brake rollers functioning as the fundamental mechanism to separate each sheet of paper for clean feeding, the scanner´s high quality technologies provide reliable paper feeding.

The Skew Reducer also helps improve feeding performance and prevents re-scanning that can result from document edges getting cut off.

Even if papers jam, the Paper Protection function keeps precious documents safe by detecting anomalies in sound and monitoring paper feed distance so that users can comfortably scan their important business documents.

Skew Reducer:- Independent separator rollers ensure that a document that is skewed will not affect the alignment of following sheets.

Minimizing risk of document damage with Paper Protection function:- The Paper Protection function detects anomalies in sound and monitors paper feed distance.

The fi-7180 keeps your important papers from being damaged.

Stress-free usability with a compact and user-friendly design Suitable for any offices:- With a very compact design, the fi-7180 fits on use anywhere, such as on desks, countertops, and inside small offices.

Easy and comfortable scanning operations:- Use the LCD operation panel and backlit display, to scan directly from the scanner with the job-registration function, and complete various operations from adjusting scanning settings to checking existing error statuses on the scanner itself.

Specifications:

- Scanner Type:ADF (Automatic Document Feeder), Duplex.

- Scanning Speed:(1) (A4 Portrait).

- (Color (2)/Grayscale (2)/Monochrome (3)):Simplex:80 ppm (200/300 dpi).

- Duplex:160 ipm (200/300 dpi).

- Image Sensor Type Color CCD x 2 (front x 1, back x 1).

- Light Source White LED Array x 2 (front x 1, back x 1).

- Optical Resolution:600 dpi.

- Output Resolution (4).

- (Color / Grayscale / Monochrome):50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver) (5).

- Output Format Color:24-bit, Grayscale:8-bit, Monochrome:1-bit.

- Background Colors White / Black (selectable).

- Document Size Maximum (6) 216 x 355.6 mm (8.5 x 14 in.).

- Minimum:50.8 x 54 mm (2 x 2.1 in.).

- Long paper scanning (7):5,588 mm (220 in.).

- Paper Weight (Thickness) Paper:27 to 413 g/m² (7.2 to 110 lb) (8).

- Plastic Card:1.4 mm (0.055 in.) or less (9)(10).

- ADF Capacity (11)(12) 80 sheets (A4 80 g/m² or Letter 20 lb).

- Expected Daily Volume (13):11,000 Sheets.

- Multifeed Detection:Overlap detection (Ultrasonic sensor), Length detection.

- Paper Protection Lag detection, Sound detection (iSOP) (14).

- Interface (15):USB 3.0 / USB 2.0 / USB 1.1.

- Power Requirements:AC 100 to 240 V ±10 %.
