Kramer KDS-EN7 Video Decoder

Kramer KDS-EN7 4K AVoIP Video Encoder for Security and Smarthome Systems

Elevate your security, surveillance, and smarthome infrastructure with the Kramer KDS-EN7, a cutting-edge AVoIP encoder designed for transmitting high-resolution video over standard IP networks. As a cornerstone of modern safety and security systems, the KDS-EN7 ensures that every detail is captured and delivered with exceptional clarity and minimal latency, making it perfect for mission-critical applications like command centers, control rooms, and enterprise-level surveillance.

The KDS-EN7 is a high performance, highly scalable AVoIP encoder delivering pristine 4K60 4:2:0 and HDR10 video over a 1G network. It is engineered to provide an excellent end user experience, making it ideal for large scale deployments where quality and reliability are paramount. With its focus on high security and easy planning and deployment, the KDS-EN7 sets a new standard for professional AV-over-IP solutions.





This powerful device takes an HDMI video source and converts it into an IP stream, allowing you to distribute video content to any point on your network. Paired with a KDS-DEC7 decoder, it creates a robust and flexible video distribution matrix that can scale from a simple point-to-point setup to thousands of endpoints, providing a future-proof solution for your growing security and automation needs.

Key Benefits:

* Unmatched Video Quality: Deliver stunning 4K resolution at 60Hz (4:2:0) and HDR10 support, ensuring that video feeds from security cameras or other sources are crystal clear, with vibrant colors and deep contrast for superior visual identification.
* Infinite Scalability: Built for large-scale deployments, the AVoIP platform allows you to expand your system effortlessly. Simply add more encoders or decoders to the network as your security or smarthome requirements grow, without the need for a costly central matrix switcher.
* Enterprise-Grade Security: Protect your sensitive video streams with advanced security features, including 802.1x authentication and HTTPS/TLS encryption, ensuring that your surveillance and AV content is shielded from unauthorized access.
* Exceptional User Experience: Experience ultra-low latency video streaming that feels like a direct connection. This is critical for real-time monitoring and control in security applications where every millisecond counts.
* Simplified Deployment & Management: The KDS-EN7 operates over a standard 1G Ethernet network, simplifying installation and reducing infrastructure costs. With Kramer Control and Kramer Network management tools, configuration and maintenance of hundreds of devices is streamlined and intuitive.

Main Features:

* High-quality 4K60 (4:2:0) video encoding
* HDR10 support for enhanced image depth and realism
* Efficient H.264/H.265 compression codecs
* Video wall and multiview processing capabilities
* Full KVM/USB support for remote device control
* Analog audio embedding and de-embedding
* RS-232 and IR signal tunneling over IP
* Power over Ethernet (PoE) for single-cable installation
* Part of the comprehensive family of Kramer Video Encoders and Decoders

Technical Specifications:

* Inputs: 1x HDMI, 1x 3.5mm Unbalanced Stereo Audio (Line In)
* Outputs: 1x HDMI (Looping), 1x 3.5mm Unbalanced Stereo Audio (Line Out)
* Ports: 1x RJ-45 Ethernet, 1x USB-B (Host), 2x USB-A (Device), 1x RS-232 (3-pin terminal block), 1x IR (3.5mm)
* Video Standards: HDMI 2.0, HDCP 2.2/1.4
* Maximum Resolution: 3840x2160 @60Hz (4:2:0)
* Compression: H.264, H.265
* Network: 10/100/1000 Base-T with PoE (IEEE 802.3af)
* Power Source: PoE or 12V DC Power Adapter
* Power Consumption: 6.5W
* Dimensions (W x D x H): 18.70cm x 11.50cm x 2.54cm (7.36" x 4.53" x 1.00")
* Weight: 0.6kg (1.3lbs)

The Kramer KDS-EN7 is more than just an encoder; it´s the intelligent heart of a secure, scalable, and high-performance video distribution network, perfectly suited for the demanding environments of modern safety, security, and advanced smarthome systems
