Startech Gigabit Ethernet To Fiber Multi Mode Converter

Convert and extend a Gigabit Ethernet connection up to 550 m / 1804 ft over Multimode LC fiber.

The ET91000LC2 1000 Mbps Gigabit Multimode Fiber Media Converter (LC, 550m) lets you extend a Gigabit Ethernet network over multimode fiber, at distances up to 550m (1804 ft).

A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-LX/SX) fiber backbone, this GbE to MM fiber converter supports full Gigabit speeds for ideal network performance and scalability.

Designed to offer a durable and convenient Ethernet-to-fiber solution, the Ethernet to LC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal configuration required.

For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U), as well as a replaceable SFP slot.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage:

- Link loss forwarding, remote status monitoring ensures maximum up-time.

- Provides Ethernet to Fiber conversion as a standalone device, or can be installed into the ETCHS2U 20 slot chassis for added versatility.

- Rugged steel casing for durability in harsh environments.

Specifications:

Network:

- Maximum data transfer rate:

2000 Mbit/s.

- Converter input interface:

1000Base-T.

- Converter output interface:

1000Base-LX,1000Base-SX.

- Ethernet interface type:

Gigabit Ethernet.

- Ethernet LAN data rates:

1000 Mbit/s.

- Auto MDI/MDI-X:

Yes.

- Duplex system:

Full, Half Ports & interfaces:

- Connectivity.

Technology:

Wired.

- Ethernet LAN (RJ-45) ports:

1.

- Fiber ports quantity:

1.

- Fiber optic connector:

LC.

- DC-in jack:

Yes.

Performance:

- Maximum transfer distance:

550 m.

- Wavelength:

850 nm.

- Fiber mode structure:

Multi-mode.

- Mean time between failures (MTBF):

65000 h Design:

- Internal:

No.

- RoHS compliance:

Yes.

-.

Certification:

CE, FCC Power:

- Output voltage:

12 V.

- Output current:

1 A.

- Power consumption (typical):

4 W.

- External power adapter:

Yes Management.

Features:

- Plug and Play:

Yes Weight & dimensions:

- Weight:

620 g Operational conditions:

- Operating temperature (T-T):

0.

- 60 °C.

- Storage temperature (T-T):

-10.

- 70 °C.

- Operating relative humidity (H-H):

10.

- 90% Packaging data:

- Package width:

206 mm.

- Package depth:

138 mm.

- Package height:

89 mm.

- Package weight:

774 g Packaging content:

- Manual:

Yes Other.

Features:

- Dimensions (WxDxH):

95 x 160 x 20 mm.

- Full duplex:

Yes.
