Ubiquiti U6-Mesh WIFI Access Point

Access Point U6 Mesh.

Elegant indoor/outdoor WiFi 6 access point designed for mesh applications.

Features:
- WiFi 6 compatibility (2.4/5 GHz bands).

5.3 Gbps aggregated throughput rate.

Horizontal antenna pattern to expand coverage area.

(1) GbE RJ45 Port (PoE In)*.

IPX5 rated weather-resistant enclosure.
- Adopt U6-Mesh in minutes with your UniFi Network application and:
- Centrally manage multiple networks from an intuitive interface.

Enjoy real-time device insights and deep configuration options.

Remotely update device firmware.

Manage network users and guests with ease.

Customize guest access point layout, architecture, and privacy.

Quickly set up devices and manage them on the go with a powerful mobile app.

Specifications.
- Network Connectivity.
- Network Interface:1 x Gigabit Ethernet RJ-45 Port.
- Management Interface:Ethernet.
- VLAN:IEEE 802.1Q.
- BSSID:Up to 8 per radio.
- Concurrent Clients:300+.
- Wireless Connectivity.
- Wi-Fi Standards:IEEE 802.11a/b/g, Wi-Fi 4, Wi-Fi 5, and Wi-Fi 6.
- Frequency Bands:2.4 GHz and 5 GHz.
- Max Throughput on 2.4 GHz:573.5 Mbps.
- Max Throughput on 5 GHz:4.8 Gbps.
- MIMO on 2.4 GHz:2x2 UL MU-MIMO.
- MIMO on 5 GHz:4x4 DL/UL MU-MIMO.
- Max Transmit Power on 2.4 GHz:22 dBm.
- Max Transmit Power on 5 GHz:26 dBm.
- Antenna Gain on 2.4 GHz:3 dBi.
- Antenna Gain on 5 GHz:5 dBi.
- Wireless Security and Management.
- Wireless Security:WPA-PSK and WPA-Enterprise with WPA, WPA2, and WPA3.
- Quality of Service:Per-user rate limiting.
- Guest Traffic Isolation:Supported.
- Supported Data Rates.
- IEEE 802.11a:6, 9, 12, 18, 24, 36, 48, and 54 Mbps.
- IEEE 802.11b:1, 2, 5.5, and 11 Mbps.
- IEEE 802.11g:6, 9, 12, 18, 24, 36, 48, and 54 Mbps.
- Wi-Fi 4 IEEE 802.11n:6.5 Mbps to 600 Mbps, MCS0 to MCS31, and 20 or 40 MHz HT Channels.
- Wi-Fi 5 IEEE 802.11ac:6.5 Mbps to 3.4 Gbps, MCS0 to MCS9, NSS1/2/3/4, and 20, 40, 80, or 160 MHz VHT Channels.
- Wi-Fi 6 IEEE 802.11ax:7.3 Mbps to 4.8 Gbps, MCS0 to MCS11, NSS1/2/3/4, and 20, 40, 80, or 160 MHz HE Channels.
- Power.
- Power Method:PoE.
- Power Supply:UniFi PoE Switch or 48V/0.32A PoE Adapter Included.
- Supported Voltage Range:44 to 57 VDC.
- Max Power Consumption:11.4 W.
- Controls and Indicators.
- LED Indicator:White and Blue.
- Installation.
- Included Mounting:Wall, Desktop, and Pole.
- Optional Mounting:Ceiling.
- Bracket Material:Plastic.
- Design and Protection.
- Housing Material:Plastic and Aluminum.
- Water Protection:IPX5.
- Dimensions:48.5 mm Diameter x 159.5 mm Height.
- Weight:400 g
