Asus ESC4000 G4/2200W server

Specifications.

Processor / System Bus.

2 x Socket P (LGA 3647).

1st and 2nd Gen Xeon® Scalable Processor Family (150W).

Core Logic.

Intel® PCH C621.

Memory.

Total Slots :
16 (8-channel, 1DPC).

Capacity :
Max.
2.048GB.

Memory Type :
DDR4 2933 RDIMM / LRDIMM / LRDIMM 3DS.

Memory Size :
128GB, 64GB, 32GB, 16GB.

Refer to support page for more information.

Expansion Slots.

Front :
1 x PCIe x8 slot (Gen3 x8 link,LP,HL) for RAID/HBA card.

Rear :
8 x PCIe x16 slots (Gen3 x16 link,FH,FL) for dual-slot GPU cards.
1 x PCIe x16 slot (Gen3 x16 link, LP, HL).
1 x PCIe x8 slot (Gen3 x8 link, LP, HL).

Storage.

Storage Controller :
Intel® PCH C621.

Optional kits Controller :
ASUS PIKE II 3008-8i 8-port SAS 12G HBA card.
ASUS PIKE II 3108-8i 8-port SAS 12G RAID card.

Drive Bays.
8x3.5´´ Hot-swap Storage Bays (Backplane Supports 6 x SATA/SAS + 2 x SATA/SAS/NVMe Devices)*.
1 x M.2 socket (SATA or Gen3 x4 link, up to 2280 module).

Networking.

2x1GbE LAN ports (RJ45, Intel I350-AM2).

Multi-GPU Support.

Please find the latest GPU support from.

https://servers.asus.com/support/GPU.

Front I/O Ports.

2 x USB 3.2 Gen1 ports.
2 x USB 2.0 ports.

Rear I/O Ports.

2 x USB 3.2 Gen1 ports.
1 x VGA port.
2x1GbE LAN ports (RJ45).
1 x Management port (RJ45).

Switch/LED.

Front :
1 x Power Button/LED.
1 x Location Button/LED.
2 x LAN LED.
1 x Message LED.
1 x HDD Access LED.

Rear :
1 x Power Button/LED.
1 x Location LED.
1 x Message LED.
1 x HDD Access LED.

Dimensions.

800x440 x 88mm.

Form Factor.

2U.

Weight.

Net Weight:
34 Kg.

Gross Weight:
44 Kg.

Power Supply.

1+1 Redundant 1600W 80 PLUS Platinum Power Supply.
Rating:
100-127Vac/200-240Vac,12.9A/9.5A, 47-63Hz.

1+1 Redundant 2200W 80 PLUS Platinum Power Supply Rating:
100-127Vac/200-240Vac,14A/12.6A, 47-63Hz.

Environment.

Operation temperature:
10 ~ 35.

Non operation temperature:
-40 ~ 70.

Non operation humidity:
20% ~ 90% ( Non condensing).

Note.The front 2 x NVMe signal is shared with the front PCIe slot (Gen3 x8 link).

Specifications:

With Fan:

Yes.

Dedicated Graphics:

Aspeed AST2500.

Graphics, Dedicated Memory:

64Mb.

HDMI:

No.

Image Output:

No.

Measurements:

800x440 x 88mm.

Microprocessor:

Intel.

Integrated Microprocessor:

No.

Multi-Graphics:

No.

Number of Memory Banks:

16.

Number of SATA Connections:

8.

Number of USB 2.0:

2.

Number of USB 3.2 Gen1:

2 Front 2 Rear.

Memory Technology:

DDR4 ECC.
