Axis TP4601-E camera support

AXIS TP4601-E Conduit Back Box | Robust Outdoor Camera Support

Elevate the security and longevity of your surveillance installation with the AXIS TP4601-E Conduit Back Box. Engineered for uncompromising performance in the most demanding environments, this robust camera support provides unparalleled protection for cabling and ensures a stable, secure mounting foundation for compatible Axis PTZ and fixed dome network cameras. Designed specifically for outdoor applications where exposure to extreme weather, potential vandalism, or corrosive elements is a concern, the TP4601-E is the professional’s choice for safeguarding critical surveillance assets.

The core benefit of this accessory lies in its exceptional durability. Constructed from marine-grade stainless steel (SS 316L), it offers superior resistance to corrosion, making it an ideal solution for installations in coastal, industrial, or chemically harsh environments. This ensures the integrity of your camera mounting over the long term, preventing degradation and maintaining system reliability. Its design facilitates a clean and secure installation, housing and protecting network and power connections from water ingress, dust, and physical impact. By providing a dedicated space for cable management and a solid interface for conduit entry, it streamlines the installation process and contributes to a professional, tamper-resistant setup.

Main Features:

* Exceptional Impact Resistance: Certified with an IK10+ rating, it is built to withstand significant physical impacts of over 50 joules, offering maximum protection against vandalism.
* Superior Weather Protection: With IP66/IP67 and NEMA 4X ratings, the enclosure is completely sealed against dust ingress and powerful water jets, and can even withstand temporary immersion, ensuring flawless operation in heavy rain, snow, and wash-down procedures.
* Corrosion-Proof Construction: Fabricated from marine-grade (SS 316L) stainless steel, it provides outstanding resistance to rust and corrosion, even in saline or polluted atmospheres.
* Flexible Conduit Installation: Features three 3/4" conduit entries, allowing for versatile and protected cable routing from walls, ceilings, or poles.

Supports:

The AXIS TP4601-E is compatible with the following Axis Network Camera series when used with their corresponding pendant kits:

* AXIS Q63 Series
* AXIS Q62 Series
* AXIS Q61-E Series
* AXIS Q60-E Series
* AXIS P56-E Series
* AXIS P55-E Series

Technical Specifications:

* Casing Material: Marine-grade, electropolished and coated stainless steel (SS 316L)
* Casing Color: Stainless steel
* Impact Resistance: IK10+ (IEC 62262)
* Ingress Protection: IP66/IP67 (IEC 60529), NEMA 4X
* Conduit Interface: 3x 3/4" or M25 conduit entries
* Operating Conditions: -50 °C to 65 °C (-58 °F to 149 °F)
* Mounting: Wall Mount. Compatible with AXIS T91B67 Pole Mount, AXIS T94V01C Dual Camera Mount, and AXIS T94N01D Pendant Kit.
* Dimensions (H x W x D): 210x195 x 65 mm (8.3x7.7x2.6 in)
* Weight: 2.3 kg (5.1 lb)
* Approvals: IEC/EN/UL 62368-1, IEC/EN/UL 60950-22, IEC 60068-2-6, IEC 60068-2-27, NEMA 250 Type 4X, IEC 62262 IK10+, IEC/EN 60529 IP66/IP67
