B-tech BTV520 65´´Fixed TV Mount

Bullet Points B-Tech BTV520 165.1 cm (65´´):
- Low profile design for a close to the wall installation
- Post installation screen alignment for perfect screen positioning
- Security locking bar to prevent unauthorised screen removal
- Suitable for concrete, brick or stud walls up to 32”
- Simple ‘hook-on’ installation
- All mounting hardware included

B-Tech BTV520 165.1 cm (65´´):
- Designed to mount large sized screens just 20mm from the wall, with its low-profile design the BTV520 is ideal for home installations. Suitable for concrete, brick or stud walls up to 32”, this mount features a simple ‘hook-on’ installation and post installation screen alignment to make screen mounting as quick and simple as possible. The BTV520 also features a security locking bar to help prevent un-authorised removal of the screen. All mounting hardware included.


Specifications:

Mounting:
- Maximum weight capacity: 70 kg
- Maximum screen size compatibility: 165.1 cm (65´´)
- Maximum VESA mount: 825 x 500 mm
- VESA mounting interfaces: 50 x 50,75 x 75,100 x 100,200 x 100,200 x 200,300 x 300,300 x 200,400 x 200,400 x 400,600 x 400,800 x 400
- Number of displays supported: 1
- Mounting type: Wall

Ergonomics:
- Distance to the wall (max): 2 cm

Weight & dimensions:
- Width: 891 mm
- Depth (max): 2 cm
- Height: 583 mm

Logistics data:
- Master (outer) case weight: 16.8 kg
- Quantity per master (outer) case: 6 pc(s)
- Master (outer) case volume: 0.049 cm³
