D-link Wireless N300 WIFI Access Point

EU Plug.

The DAP-2020 Wireless N Access Point allows your business to create a secure and manageable wireless network.

Multiple operational modes, network management tools and security features gives network administrators more flexible deployment options.

The DAP-2020 can be wall mounted or placed on a desktop to meet any wireless demands.

Secure Your Wireless Network The DAP-2020 provides 64/128-bit WEP encryption and WPA/WPA2 security to protect your network and wireless data.

This device also supports Wi-Fi Protected Setup (WPS) to quickly and securely set up a wireless network.

In addition, the device features MAC address filtering and the ability to disable SSID broadcasting, preventing unauthorised access to your home or office network.

Multiple Operation Modes:- The DAP-2020 offers seven different modes of operation.

These modes allow you to flexibly configure the device to suit a variety of different wireless applications.

Access point mode allows the device to act as a central hub for wireless users.

Wireless client mode enables the DAP-2020 to connect to another access point.

Bridge mode can join two wired networks together, while bridge with AP mode allows the device to act as a wireless hub and as a bridge at the same time.

Repeater mode extends wireless coverage to cover all dead spots.

WISP client router mode allows wireless Internet service subscribers to share an Internet connection with wired home/office computers without the need for an extra router.

Finally, the device can act as a WISP repeater (range extender) to let WISP subscribers share their Internet connection with wired and wireless computers, without any additional routers.

Specifications:

- 2.4 GHz:Yes.

- 5 GHz:No.

- Maximum data transfer rate:300 Mbit/s.

- Ethernet LAN data rates10,100 Mbit/s.

- Frequency band2.4.

- 2.4835 GHz.

- Networking standardsIEEE 802.3i,IEEE 802.3u.

- ModulationCCK,DBPSK,DQPSK,OFDM.

- Quality of Service (QoS) supportYes.

Security:- Security algorithms:WPA,WPA2 Management.

Features:

- Web-based managementYes.

Ports & interfaces:- Ethernet LAN (RJ-45) ports:1.

- DC-in jackYes.

Power:- Input voltage12 V.

- Input current0.5 A.

- Power consumption (max)2.25 W Design:- Reset buttonYes.

- CertificationWi-Fi, CE.

- InternalNo Antenna:- Antennas quantity2 Operational conditions:- Operating relative humidity (H-H)10.

- 90%.

- Operating temperature (T-T)0.

- 40 °C.

- Storage temperature (T-T)-20.

- 65 °C Operational conditions:- Storage relative humidity (H-H)5.

- 95% Technical details:- Shipping (inner) case length57.1 cm.

- Shipping (inner) case width36 cm.

- Shipping (inner) case height24 cm.

- Shipping (inner) case gross weight6.7 kg.

- Shipping (inner) case net weight6 kg.

- Quantity per shipping (inner) case10 pc(s).

- Pallet gross weight (air)223 kg.

- Number of cartons per pallet (air)30.

- Quantity per pallet (air)300 pc(s).

- Pallet length120 cm.

- Pallet width110 cm.

- Pallet height (air)133.5 cm.

- Pallet gross weight (sea)343.6 kg.

- Number of cartons per pallet (sea)48.

- Quantity per pallet (sea)480 pc(s).

- Pallet height (sea)2.06 m.

Weight & dimensions:- Width:147.5 mm.

- Depth:113 mm.

- Height:31.5 mm.

- Weight224.7 g Packaging data:- Package width208 mm.

- Package depth274 mm.

- Package height68 mm.

- Package weight600 g.
