Digitus 24x CAT 6A Keystone Module+tool Montage network cable

FEATURES:
- Strain relief and cable fixation with intelligent cable manager
- 360° shield contact
- Suitable for field assembly (tool-free mounting)
- Designable - suitable for distribution panel and junction box mounting
- CAT 6A with LSA insulation displacement contacts
- Dust protection cap for RJ45 jack
- Category 6A 10GBase-T, 500 MHz
- Suitable for PoE/PoE+ (IEEE 802.3af, 3at)
- Suitable for distribution panel and junction box mounting
- RJ45 jack, 8P8C
- Cable installation via insulation displacement connectors, color-coded according to EIA/TIA 568 A & B
- Strain relief and cable fixation with intelligent cable manager
- Tool-free mounting connection
- 360° shield contact
- Material housing: zinc die-cast - nickel-plated
- Contact material: phosphor bronze
- Coating contacts: Nickel, gold-plated 0.5 µ
- Insertion force: Max. 30N (according to IEC 60603-7-51)
- Holding force: 7.7 kg between socket and plug
- Operating temperature: -20 °C up to +70 °C (ISO/IEC 11801, ANSI/TIA 568 C.2)
- Mating cycles: ≥ 750 (ISO/IEC 11801, IEC 60603-7-51)
- Copper conductor diameter: AWG (26/7 - 22/1), strands and solid wire
- Tested with AWG 22/1 solid installation cable
- Dielectric strength: 1000 VDC (contact/contact), 1500 VDC (contact/ground)
- Tool-free installation using LSA insulation displacement connectors, color-coded according to EIA/TIA 568 A & B
- Intelligent cable manager (reclosable)
- Dimensions (HxWxD): 21.0 x 14.5 x 34.5 mm
- Weight: 19.5 g
- Design: Socket (Jack)
- Connection type: LSA
- Shielded: yes
- Kategories: 6A (IEC)
- Suitable for round cables: yes
- Suitable for flat cable: no
- Suitable for stranded conductors: yes
- Suitable for solid conductors: yes
- Connector type: RJ45 8(8)
- AWG range: 26 ... 22
- Special tool required: no
