Digitus DS-12874 KVM Switch

EU Plug.

DIGITUS DS-12874 4-Port KVM Switch, 1-User, VGA, USB with Audio Streamline your server management and declutter your workspace with the DIGITUS DS-12874 4-Port KVM Switch.

Designed for professional IT environments, this robust device allows you to control up to four computers or servers from a single console, consisting of one VGA monitor, one USB keyboard, and one USB mouse.

Eliminate the need for multiple sets of peripherals, saving valuable desk or rack space and significantly improving workflow efficiency.

With its integrated USB hub and full audio support, the DS-12874 is the complete solution for managing multi-computer setups in server rooms, data centers, and advanced workstations.

The durable metal housing and included rack mount kit ensure seamless integration into any standard 19´´ server rack.

Key Benefits -Centralized Control:

Effortlessly manage and operate up to four PCs or servers from a single console, reducing hardware clutter and simplifying complex tasks.

-Peripheral Sharing:

An integrated 2-port USB 2.0 hub allows you to share peripherals like printers, scanners, or external hard drives among all connected computers, saving costs and space.

-Full Multimedia Experience:

Transmit audio signals with dedicated 3.5mm jacks for both microphone and speakers, enabling a complete multimedia workstation experience without swapping cables.

-Superior Video Quality:

Supports high-resolution video up to 2048x1536 pixels, ensuring crisp, clear visuals for detailed server monitoring and graphic-intensive applications.

-Flexible Operation:

Switch between connected computers with ease using three convenient methods:

front-panel push buttons, intuitive hotkey commands from your keyboard, or the comprehensive On-Screen Display (OSD).

-Professional Integration:

The sturdy metal chassis is built for durability, and the included mounting brackets allow for easy installation into a 1U slot in any standard 19-inch server rack.

Main Features -Controls four computers from a single USB console -Integrated 2-port USB 2.0 hub for peripheral sharing -Audio enabled for speaker and microphone support -Switching via front-panel buttons, hotkeys, or On-Screen Display (OSD) -Hot-pluggable and hot-swappable functionality -Auto-scan mode for monitoring all connected computers -LED indicators for easy status monitoring -Supports DDC2B for optimal monitor detection -No software or driver installation required -Cascadable design to control more computers Attribute -Type:

KVM Switches Technical Specifications -PC Connections:

4 -Console Connections:

1 -1 x HDB-15 VGA Female (Video) -2 x USB Type-A Female (Keyboard, Mouse) -2x3.5mm Audio Jack Female (Mic, Speaker) -2 x USB 2.0 Type-A Female (Hub) -Computer Ports:

4 x SPHD-15 Female (for KVM cables) -Max.

Video Resolution:

2048x1536 @ 65Hz -Scan Interval:

5 - 99 seconds (programmable) -Housing:

Metal -Mounting:

19´´ Rack Mountable (1U), brackets included -Power Supply:

External DC 9V, 1A Power Adapter -Operating Systems Supported:

Windows, Mac, Linux, and Sun -Dimensions (L x W x H):

220x105 x 45 mm -Weight:

880 g -1 x KVM Switch, 4-Port -4 x KVM Cable (1.8m) -1 x Power Adapter -1 x Rack Mount Kit -1 x User Manual.
