Equip RJ45 FTP CAT 7 network cable 1 m

The equip® Cat.6A Pro S/FTP Patch Cord is composed of preeminent materials and fully-examined to conform with industrial standards. Offering higher bandwidth and better signal-to-noise margin, the Cat.7 cable is able to deliver ultrahigh and error-free performance in the most demanding network environments, specially for 10G application.

- 26AWG
- Standard CAT.7 Copper Cable
- PIMF (Pairs In Metal Foil)
- Stranded bare copper conductor
- Gold Plated Connectors for high signal quality
- Molded boot with Strain relief
- RoHS compliant
- Low Smoke Zero Halogen (LSZH/LSOH)


Specifications:

- Cable length: 1 m
- Cable standard: Cat7
- Cable shielding: S/FTP (S-STP)
- Connector 1: RJ-45
- Connector 2: RJ-45
- Connector 1 gender: Male
- Connector 2 gender: Male
- Jacket material: Low smoke zero halogen (LSZH)
- Conductor type: Stranded
- AWG wire size: 26
- Transfer rate: 10000 Mbit/s
- Frequency: 600 MHz

Features:
- Certification: UL/CUL, TIA/EIA, 3P

Weight & dimensions:
- Width: 10.7 mm
- Depth: 11.7 mm
- Height: 1000 mm
- Outer diameter: 6.1 mm
- Weight: 50 g

Packaging data:
- Package width: 175 mm
- Package depth: 275 mm
- Package height: 1 mm
- Package weight: 53.125 g

Technical details:
- Sustainability certificates: RoHS
- Doesn´t contain: Halogen
