Kramer T-IN4-REC2 Connectivity box

Kramer T-IN4-REC2: The Ultimate 4K Receiver & Room Controller for Modern Collaboration Spaces

Elevate your meeting rooms, classrooms, and huddle spaces with the Kramer T-IN4-REC2, a high-performance receiver and room controller engineered for seamless connectivity and effortless control. Designed as the central hub of your AV installation, this device is part of a new generation of smart connectivity boxes that simplify complex setups, reduce clutter, and empower users with intuitive, plug-and-play operation. The T-IN4-REC2 consolidates multiple signal types, advanced control capabilities, and audio amplification into a single, powerful unit, creating a sophisticated and reliable environment for presentation and collaboration. Experience the future of integrated room solutions, where powerful technology works silently in the background to ensure your meetings run smoothly and professionally.

Key Benefits
* Streamlined Installation: Drastically reduce cable clutter and installation complexity by extending multiple video, audio, and control signals over a single, long-reach HDBaseT cable.
* Effortless Collaboration: Foster a dynamic meeting environment with intelligent auto-switching, which automatically detects and selects the last connected source, eliminating the need for manual intervention and ensuring a smooth start to any presentation.
* Total Room Automation: Gain centralized control over your entire room environment. Effortlessly manage displays, projectors, screens, and lighting through integrated CEC, RS-232, GPIO, and relay controls, creating a fully automated and smart space.
* Uncompromised Visual Fidelity: Deliver stunning, crystal-clear presentations with support for ultra-high-definition video. Your content will be displayed with exceptional detail and clarity, making a powerful impact on your audience.
* Flexible and Future-Proof: With a versatile array of inputs and robust processing, the T-IN4-REC2 is equipped to handle both current and future AV technology, ensuring a long-term return on your investment.

Main Features
* High-Performance 4-Input Receiver
* Integrated Room Automation Controller
* HDBaseT 2.0 Signal Technology
* High-Resolution 4K Video Support
* Intelligent, Priority-Based Auto-Switching
* Step-In Functionality for Collaborative Switching
* Bi-directional RS-232 and Ethernet Control Tunneling
* CEC (Consumer Electronics Control) Automation
* Integrated 2x20W Power Amplifier
* Microphone Input with Phantom Power Selection
* Line-Level Stereo Audio Input and Output
* Convenient Web-Based Management and Configuration
* PoE (Power over Ethernet) Provider

Technical Specifications
* Inputs: 1 HDBaseT on RJ-45, 2 HDMI, 1 VGA on 15-pin HD with 3.5mm Unbalanced Stereo Audio, 1 Microphone on 3-pin Terminal Block, 1 Unbalanced Stereo Audio on 3.5mm mini-jack
* Outputs: 1 HDMI, 1 Stereo Speaker Output on 4-pin Terminal Block, 1 Unbalanced Stereo Audio on 5-pin Terminal Block
* Ports: 1 Ethernet on RJ-45, 1 RS-232 on 3-pin Terminal Block, 1 GPIO on 4-pin Terminal Block, 1 IR on 3.5mm mini-jack
* Max Data Rate: 10.2Gbps (3.4Gbps per graphic channel)
* Max Resolution: 4K@60Hz (4:2:0) 24bpp
* Compliance: HDCP 1.4
* Amplifier: 2x20W @ 4Ω
* Supported Formats: Dolby Digital 5.1, Dolby Digital TrueHD, DTS 5.1, DTS–HD
* HDBaseT Range: Up to 40m (130ft) at 4K@60Hz (4:2:0); up to 70m (230ft) at 1080p
* Consumption: 12V DC, 5A
* Chassis Type: Aluminum
* Cooling: Convection Ventilation
