Lanberg FF01-6827-12B rack cabinet

Lanberg FF01-6827-12B 27U Free-Standing Server Rack Cabinet | 600x800mm

Elevate your IT infrastructure with the Lanberg FF01-6827-12B, a professional-grade 27U free-standing server rack cabinet designed for robust, secure, and organized housing of network equipment, servers, and storage systems. Engineered for small to medium-sized businesses, data centers, and server rooms, this cabinet provides a stable and controlled environment for your critical hardware, ensuring optimal performance and longevity. Its sleek, black finish (RAL9004) and modern design integrate seamlessly into any professional setting.

Key Benefits

The Lanberg FF01-6827-12B is built to provide a comprehensive solution for your hardware management needs. It offers exceptional security with a lockable tempered glass front door, allowing for visual monitoring of device status without compromising safety. The solid steel, lockable side and rear panels further prevent unauthorized access. Its intelligent design promotes superior passive airflow, while dedicated mounting points for fan units enable active cooling solutions to protect your valuable equipment from overheating. The cabinet´s impressive static load capacity of up to 800 kg ensures it can support a full complement of heavy servers, UPS units, and networking gear with complete stability.

Main Features

* Enhanced Security: Equipped with a front tempered glass door with a lock, and solid steel, lockable side and rear panels.
* Flexible Equipment Mounting: Features two pairs of adjustable 19" vertical mounting rails (front and rear) to accommodate various device depths and configurations.
* Optimized Cable Management: Includes top and bottom panels with convenient cable entry points, simplifying wiring and maintaining a clean, organized setup that improves airflow and accessibility.
* Effective Thermal Management: Designed with passive ventilation points and prepared for the installation of dedicated fan units in the top and bottom panels.
* Easy Installation and Mobility: Delivered in a flat-pack for convenient transport and assembly. The package includes both heavy-duty castors for mobility and adjustable leveling feet for stable, permanent placement.
* Durable Construction: Manufactured from high-grade cold-rolled steel for maximum durability and protection of internal components.

Internal Organization and Decks

The 19-inch standard mounting system of the Lanberg FF01-6827-12B provides a versatile framework for internal organization. While the cabinet is designed for rack-mountable equipment, its universal structure allows for the easy installation of various optional accessories. You can create customized horizontal platforms, or Decks, by adding fixed or sliding shelves. These decks are perfect for housing non-rack-mountable equipment such as tower PCs, modems, or monitoring tools, allowing you to maximize the use of the 27U vertical space and create a layered, highly efficient equipment layout.

Technical Specifications

* Cabinet Type: Free-standing
* Height (U): 27U
* Dimensions : 600x800 x 1388 mm
* Maximum Static Load: Up to 800 kg
* Protection Class: IP20
* Material: High-quality cold-rolled steel
* Front Door: Tempered glass with lock
* Rear Door: Solid steel with lock
* Side Panels: Solid steel, removable with locks
* Color: Black RAL9004
* Mounting Rails: 2 pairs, adjustable depth
* Cable Entry: Top and bottom panels
* Included Accessories: Keys for locks, castors, adjustable feet, M6 cage nuts
* Standards Compliance: ANSI/EIA RS-310-D, IEC297-2, DIN41494; PART1 & PART7, ETSI
