Level One FPS-1032 PCI-E Expansion Card

Product Overview.

The LevelOne FPS-1032 print server is an ideal network printing solution for small offices, home offices, schools and other businesses that require printer sharing over the same network.

This print server is equipped with a 10/100Mbps autosensing Ethernet port and a USB 2.0 port that connected to USB printer.

Multi OS and Network Printing Protocol Support.

The FPS-1032 1-port USB print server supports Windows ME T/2000/XP/2003/Vista and Win7 operating systems as well as Mac OS 8.1 and higher, UNIX/Linux and Netware (Bindery DS).

Network Protocol supported includes TCP/IP, IPX, NetBEUI, AppleTalk, LPR and SMB over TCP/IP for flexible use with different network clients connected to the same office network.

The FPS-1032 also includes Internet Printing Protocol (IPP) support and Windows Print Monitor Technology to monitor printing jobs received.

Easy Installation Wizard.

The LevelOne FPS-1032 is easily configurable using a Web Browser or Windows based configuration program included with the CD-ROM.

The print server is easily managed through a Web based user interface and the firmware is upgradeable through TFTP, the windows set-up program or the Web based user interface.

- USB print server for network print sharing.

- USB 2.0 interface.

- Simple setup with user-friendly interface.

- Support multiple network printing protocols.

- Support multiple operating systems.

LevelOne USB Print Server.

Product colour:Black, Green, LED indicators:Activity, Link, Power, Status, Country of origin:Taiwan.

Network connection type:Ethernet LAN, Networking standards:IEEE 802.3, IEEE 802.3u, Ethernet LAN data rates:10,100 Mbit/s.

Supported network protocols:TCP/IP, IPX, NetBEUI, AppleTalk, LPR, RAW TCP, SMB over TCP/IP.

USB connector type:USB Type-A.

Windows operating systems supported:Windows 2000, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home.

, Mac operating systems supported:Mac OS 8.1, Mac OS 8.5, Mac OS 8.6, Mac OS 9.0, Mac OS 9.1, Mac OS 9.2, Other operating systems supported:Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x.
