PNI Remote Control For CA500 Relay

Additional remote control for PNI CA500 relay


Features:

Additional remote control for CA500:
- The relay with the PNI CA500 remote control in the picture below allows a wide range of applications being able to control garage doors, access gates, elevators, electromagnetic yokes, etc.
- The device allows the control with the help of the 2 remote controls in the package.
- But the number of remote controls can increase, so the additional remote control is perfectly compatible with the relay CA500.
- The remote control works with 23A / 12V type batteries which is included.

Learning a new remote control:
- For pairing new remote controls with your relay you must follow the steps below:
- Briefly press the learning button. The LED lights up. Press the A button on the remote control. The red LED blinks 3 times and then lights up to confirm the learning of the - A button for the command of the first relay. The red LED remains lit.
- Press the B button on the remote control. The red LED flashes 3 times and then goes out to confirm the learning.
- Repeat the procedure for learning additional remote controls.
image description


Specifications:

- Channels: 2
- Feeding: 12V
- Temperature of use: -40 ~ + 80 ° C
- Remote: 1 pc
- Battery Remote Control: Alkaline type 23A 12V (included)
