Startech 8K DisplayPort 1.4 Cable displayport cable 2 m 60Hz

This DisplayPort 1.4 cable connects your DisplayPort™ laptop or desktop computer to an ultra-high definition 8K monitor, TV or projector. It supports resolutions up to 8K (7680 x 4320) at 60Hz.

The DisplayPort monitor cable provides the essential connection to support the next generation of ultra-high definition video.

This cable is VESA® Certified to ensure full compliance and efficient operation of the higher link rate of HBR3. It has been tested to meet all DP 1.4 specifications to ensure quality and reliability.


Features:

- High Performance: 6.6ft (2m) VESA Certified DisplayPort 1.4 cable; 8K 60Hz (7680x4320p), 4K 120Hz (3840x2160p), 32.4Gbps bandwidth, HDR10, 32Ch Audio, MST, GTC for precise audio channel timing; future-proof your equipment by making it 8K ready
- Reliable: 34 AWG video cable built with internal wire manager to ensure signal integrity; Metal connector sub-structure & Al-Mylar Foil w/Braid (85% coverage) for superior EMI shielding; Gold-plated latching DP connectors prevent accidental disconnection
- Durable: Tested to withstand 5000+ insertions & 300+ bend cycles at 120° angle; Long lasting TPE jacket w/ molded Soft TPE strain relief absorbs stress of frequent bends; TPE is non-toxic, halogen free & RoHS certified for environmental sustainability
- Applications: 8K DisplayPort cable for home or professional workstations w/ Radeon Vega Frontier/Pro WX Series 2100/3100/5100/7100/W5500, Pro Duo 2000 & Nvidia Quadrop GP100, GV100/RTX™ 4000; Dell XPS 11th Gen, HP Z2 G8; Connect to DP monitor/display/TV

This 8K DisplayPort cable supports all DP 1.4 features:
- High Bit Rate 3 (HBR3) Bandwidths of 32.4 Gbps supporting the latest in industry standards
- High Dynamic Range (HDR10) for higher contrast ratio and vivid colors
- Multi-Stream Transport (MST) for daisy-chaining multiple monitors
- Display Stream Compression 1.2 (DSC) for maximum resolution output
- Forward Error Correction to manage data transmission errors
- High-Bandwidth Digital Content Protection (HDCP 2.2) for a secure connection between source and display
- 32 Uncompressed Digital Audio Channels

Cable Key Features:
- Aluminum-mylar foil with braided shielding improve EMI protection
- Long lasting flexible TPE jacket & strain relief (TPE is non-toxic & halogen free for environmental sustainability)

Connector Key Features:
- Die-cast aluminium sub-structure shielding improves signal integrity & prevents signal degradation
- Corrosion-free gold-plated connectors ensure premium video quality & enhanced reliability
- Tested to withstand 5000+ insertions

8K: Enabling Business Continuity:
- 8K has a resolution of 7680 x 4320 and is also known as 4320p and Ultra High Definition (UHD). Suitable for digital signage and other commercial displays that require the highest available resolution. This cable is backward compatible with 4K and 5K displays making it the perfect peripheral to start futureproofing your cabling infrastructure.


Specifications:

Connector(s):
- Connector A: 1 - DisplayPort (20 pin)
- Connector B: 1 - DisplayPort (20 pin)

Environmental:
- Operating Temperature: 0°C to 50°C (32°F to 122°F)
- Storage Temperature: 0°C to 50°C (32°F to 122°F)
- Humidity: 0%RH ~ 85%RH

Hardware:
- Active or Passive Adapter: Passive
- Number of Conductors: 19
- Connector Plating: Gold
- Cable Jacket Material: TPE - Thermoplastic Elastomers
- Cable Shield Material: Aluminum-Mylar Foil with Braid

Performance:
- Maximum Data Transfer Rate: 32.4Gbps
- Maximum Digital Resolutions: 8K 60Hz (7680 x 4320)

Audio Specifications:
- DisplayPort - 7.1 Channel Audio
- DisplayPort - 5.1 Channel Audio

Physical Characteristics:
- Product Height: 1.2 cm [0.5 in]
- Weight of Product: 68.0 g [2.4 oz]
- Product Length: 2.0 m [6.6 ft]
- Product Width: 2.0 cm [0.8 in]
- Wire Gauge: 34 AWG
- Cable Length: 2 m [6.6 ft]
- Cable OD: 4.5 mm [0.2 in]

What´s in the Box:
- Included in Package: 1 - Displayport 1.4 8K Cable
