Startech Mounting Bracket VESA Desk Support

Save valuable desk space and position your monitor in a more comfortable viewing position. Constructed of high-grade steel, this monitor desk mount for up to 34´´ monitors makes it easy to suspend your display above your desk or other work surface.

Work in Comfort While Saving Desk Space:
- Clear up your desk surface while creating an ergonomic workspace. This simple yet rugged single monitor mount supports displays 13´´ to 34´´ in size and up to 17.6 lb. (8 kg) in weight.

Easy Height Adjustment Along the Pole:
- With the height adjustable monitor arm, you can also adjust the height of your monitor along the vertical pole to a maximum height of 17.3´´ (439 mm) to your desired position, to help reduce neck and eye strain.

Adjust your Screen Position:
- Easily rotate, tilt and swivel, to adjust your screen position and find the perfect viewing angle.

Rugged Steel Construction:
- The heavy duty monitor arm is made of steel for long-lasting performance. The surface finish features a powder coating to help resist scratches.

Easy and Flexible Installation:
- The desk clamp monitor mount makes it easy to mount a VESA mount compatible display above your desk, using the included C-clamp or grommet mount. A detachable VESA panel enables simple attachment of your monitor, then you just slide your monitor onto the mount. To help keep your work area free of clutter, the monitor mount also features cable management clips that keep your cables neatly out of sight.

The ARMPIVOTV2 is backed by a StarTech.com 5-year warranty and free lifetime technical support.


Specifications:

Warranty Information:
- Warranty:5 Years

Hardware:
- Cable Management:Yes
- # of Displays Supported:1
- Mounting Options:Desk & Grommet Clamp
- Wallmountable:No

VESA Hole Pattern(s):
- 75x75 mm
- 100x100 mm

Mounting Surface Thickness:
- Desk Clamp: Table Thickness 0.39 - 3.46 in. (10 - 88 mm)
- Grommet Clamp: Table Thickness 0.39 - 2.95 in. (10 - 75 mm)
- Grommet Mount Hole Size: 0.41 - 1.96 in. (10.5 - 50 mm)

Packaging Information:
- Package Height:4.4 in [112 mm]
- Package Length:5.0 in [12.8 cm]
- Shipping (Package) Weight:6.8 lb [3.1 kg]
- Package Width:19.4 in [49.3 cm]

Performance:
- Weight Capacity (Per Display):8000
- Minimum Display Size:13´´
- Maximum Display Size:34´´
- Fits Curved Display:Yes
- Fits UltraWide Displays:Yes
- Height Adjustment:Yes
- Maximum Height:439.4
- Maximum Arm Extension:88
- Display Tilt+ 45° / - 45°
- Swivel / Pivot:+90° / -90°
- Display Rotation:360°

Physical Characteristics:
- Weight of Product:83.1 oz [2355.049 g]
- Material:Steel and Plastic
- Product Length:4.5 in [11.4 cm]
- Product Width:21.6 in [548 mm]
- Product Height:5.8 in [14.8 cm]
- Special Notes / Requirements:Note

This mount supports monitors up to 34”, including flat screen, curved and ultrawide displays, with a max weight of 17.7 lb. (8 kg). If you choose to use an ultrawide display in portrait position, the mount supports ultrawide displays with a max width of 28´´ (71 cm).

What´s in the Box:
- Included in Package
- 1 - VESA monitor mount
- 1 - VESA pole clamp
- 1 - pole
- 3 - pole screws
- 1 - desk clamp
- 1 - grommet plate
- 1 - grommet collar
- 1 - cable-management clip
- 5 - rubber pads
- 1 - thumbscrew
- 1 - 4 mm hex key
- 1 - 6 mm hex key
- 4 - M4x12 mm screws
- 4 - M4x16 mm screws
- 4 - M5x12 mm screws
- 4 - M5x16 mm screws
- 4 - spacers
- 4 - washers
- 1 - instruction manual
