Startech PCIe Dual Port 10GB NIC Base-T PCI-E Expansion Card 10G

Dual Nic Card Windows & Mac 2 X Rj45 X8 Pcie 2.X Low-Profile Bracket Incl.

- This Dual-Port 10gb Pcie Network Card Offers A Versatile And Low-Cost Way To Deploy 10gbe Network Connectivity.

It Adds Two Copper Ethernet Ports To Your Server Or Desktop Computer And Provides Multi-Gigabit Ethernet Access To Your Network At Five Speeds:

10g, 5g, 2.5g, 1g And 100mbps.

- Cost-Effective Multi-Gigabit Ethernet Solution.

- The 10gbase-T Nic Provides Additional Bandwidth Using Your Existing Ethernet Infrastructure To Help Reduce The Cost Of Cabling Upgrades.

The Card Enables You To Connect To 10gbase-T And Nbase-T Equipment At Network Speeds Of:

- 100mbps, 1gbps, 2.5gbps Or 5gbps Over Your Cat5e Cabling (Up To 100 M).

- 10gbps Over Your Cat6 Or Better Cabling (Up To 100 M) Optimal Technology For Optimal.

Performance:

- The Network Adapter Card Adds Two Ethernet Ports To Your Workstation Through An X8 Pcie 2.X (Or Higher) Slot.

It Features 10gbase-T Technology, Supporting Advanced Multi-Gigabit Systems, Including Cisco Campus Switches And Aruba Networks Access Points.

The Nic Card Also Supports Additional Features Including 9k Jumbo Frames, Autonegotiation, Auto-Mdix And 802.1q Vlan Tagging.

Energy Efficient Ethernet:

- The Dual Tehuti Tn4010 + Marvell 88x3110 Chipset, Compliant With Ieee 802.3az, Ensures Peak Operation And Reduced Power Consumption.

The Decreased Consumption Minimizes The Heat Generated To Avoid Operating Temperatures Increasing Within Your Server Case.

The Startech.Com Advantage:

- Multi-Gigabit Ethernet Connectivity With Five Network Speeds:

10g, 5g, 2.5g 1g And 100mbps.

- Compatible With Both 10gbase-T And Nbase-T Specifications.

- Supports 2.5 And 5gbps Network Speeds On Cat5e Cabling And 10gbps On Cat6a.

Specifications:

Ports & Interfaces:

- Connectivity.

Technology:

Wired.

- Host Interface:

Pci Express.

- Interface:

Ethernet.

- Ethernet Lan (Rj-45) Ports:

2.

- Pci Version:

2.0 Network:

- Maximum Data Transfer Rate:

10000 Mbit/S.

- Networking Standards:

Ieee 802.1q,Ieee 802.3ab,Ieee 802.3ad,Ieee 802.3an,Ieee 802.3az,Ieee 802.3u.

- Ethernet Lan:

Yes.

- Ethernet Interface Type:

2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet.

- Ethernet Lan Data Rates:

100,1000,2500,5000,10000 Mbit/S.

- Cabling.

Technology:

10gbase-T.

- Copper Ethernet Cabling.

Technology:

10gbase-T,100base-T,1000base-T.

- Auto Mdix Ieee:

Yes.

- Jumbo Frames Support:

Yes.

- Vlan Tagging:

Yes Design:

- Internal:

Yes.

- Chipset:

Tehuti Tn4010, Marvell 88x3110.

- Led Indicators:

Activity, Link.

- Rohs Compliance:

Yes.

-.

Certification:

Ce, Fcc, Reach Operational Conditions:

- Operating Temperature (T-T):

5.

- 50 °C.

- Storage Temperature (T-T):

-20.

- 60 °C.

- Operating Relative Humidity (H-H):

20.

- 80% System Requirements:

- Windows Operating Systems Supportedwindows 10,Windows 10 Education,Windows 10 Enterprise,Windows 10 Enterprise X64,Windows 10 Home,Windows 10 Home X64,Windows 10 Iot Core,Windows 10 Pro,Windows 10 Pro X64,Windows 10 X64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise X64,Windows 7 Home Basic,Windows 7 Home Basic X64,Windows 7 Home Premium,Windows 7 Home Premium X64,Windows 7 Professional,Windows 7 Professional X64,Windows 7 Starter,Windows 7 Starter X64,Windows 7 Ultimate,Windows 7 Ultimate X64,Windows 7 X64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise X64,Windows 8 Pro,Windows 8 Pro X64,Windows 8 X64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise X64,Windows 8.1 Pro,Windows 8.1 Pro X64,Windows 8.1 X64 Mac Operating Systems Supportedmac Os X 10.12 Sierra, Mac Os X 10.13 High Sierra, Mac Os X 10.14 Mojave.

- Linux Operating Systems Supported:

Yes.

- Other Operating Systems Supported:

Vmware Esx/Esxi 5.0.

- Server Operating Systems Supported:

Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016,Windows Server 2019 Weight & Dimensions:

- Width:

159 Mm.

- Depth:

121 Mm.

- Height:

20 Mm.

- Weight:

390 G Packaging Data:

- Low-Profile Bracket:

Yes.

- Package Width:

159 Mm.

- Package Depth:

121 Mm.

- Package Height:

20.5 Mm.

- Package Weight:

400 G Other.

Features:

- Quick Start Guide:

Yes.

- Jumbo Frames:

9000.
