Tp-link INSIGHT S485 4 mm security camera

Technical sheet

Tp-link INSIGHT S485 4 mm security camera

Name: Tp-link INSIGHT S485 4 mm security camera
Brand: Tp-link
SKU: 142075259
Price: 185.49 EUR
Availability: InStock
Rating: 4 (1 reviews)

Price without code 185.49

RRP:

You save:

Price without subscription

VAT & duties included

1 Reviews

0 Questions

No extra charges at delivery.

Size

Long

What is my size?

My virtual fitting room

Stringing

Unstrung

Tension

18 Kg
19 Kg
20 Kg
21 Kg
22 Kg
23 Kg
24 Kg
25 Kg
26 Kg
27 Kg
28 Kg
29 Kg
30 Kg
31 Kg
32 Kg
33 Kg
34 Kg
35 Kg
36 Kg

To adjust your bindings, type in the following informations:

(Customized items cannot be returned or exchanged)

It´s free!

(Customized items cannot be returned or exchanged)

Single purchase

Add to my pack

You save:

Buy now in 1 click

Back to PC configurator

Buy this product and earn

Color:

Free shipping

dto_trans discount on shipping

Free assembly

Free removal of old appliance (only with Ader)

Your interest-free financing from with Klarna Paypal

Pay in 3, 4, 6 or up to 12 installments

My virtual fitting room

Other colors available

Perfect pairings

Reportar error

Trusted by over 25 million satisfied customers worldwide

Official brand warranty

Quick & easy 30-day return

Features of Tp-link INSIGHT S485 4 mm

Product description of Tp-link INSIGHT S485 4 mm security camera

Description summary

Secure your space with the TP-LINK INSIGHT S485 4mm security camera. This robust, weatherproof turret camera offers crystal-clear 8MP resolution with H.265+ compression, ensuring detailed footage day or night thanks to infrared and white LEDs. Its wide 109.6° diagonal field of view, 21m recognition distance, and 120dB dynamic range capture every detail. Featuring 2-way audio, a built-in siren, and motion detection with alert notifications, it provides comprehensive surveillance. Power options include DC and PoE, with cloud management for ultimate convenience and remote viewing. With IP67 protection and a durable metal housing, it´s built for any outdoor environment

Specifications:

- Number of microphones: 1
- Bit rate range: 0 - 64 Kbit/s
- Built-in speakers: Yes
- Audio system: 2-way
- Built-in microphone: Yes
- Supported audio formats: G.711 A-law
- Audio input channels: 1 channels
- Audio output channels: 1 channels
- Sampling frequency: 8 kHz
- Recognition distance: 21 m
- Focal length interval: 4 mm
- Fixed focus: Yes
- Width: 111 mm
- Height: 83.7 mm
- Weight: 480 g
- Length: 111 mm
- Power supply: DC, PoE
- DC output voltage: 12
- Power consumption (max): 11.5 W
- Power consumption (Power over Ethernet, PoE): 12.5 W
- Operating temperature range: -30 - 60 °C
- Storage temperature range: -40 - 60 °C
- Operating relative humidity: 0 - 95%
- Storage relative humidity: 0 - 95%
- Live View: Yes
- Ethernet: Yes
- Supported network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
- Bitrate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Video recording: Yes
- Maximum resolution: 3840 x 2160 pixels
- Video compression formats: H.264, H.264+, H.265, H.265+
- Digital Wide Dynamic Range (DWDR): Yes
- Total megapixels: 8 Mpx
- Backlight compensation (BLC): Yes
- Bit rate: Main Stream: 256 Kbps to 8 Mbps, Sub-Stream: 64 Kbps to 512 Kbps
- Highlight Compensation (HLC): Yes
- Compatible Memory Cards: MicroSD (TransFlash)
- Maximum Memory Card Size: 512 GB
- Built-in Siren: Yes
- Video Motion Detection: Yes
- Mirror: Yes
- Motion Sensor: Yes
- Alert Notification Type: Pop-up Notification
- Optical Sensor Size: 25.4 / 2.7 mm (1 / 2.7´´)
- Sensor Type: CMOS
- Progressive Scan: Yes
- Managed Via Cloud: Yes
- Reset Button: Yes
- Web Browser: Yes
- Lens Angle of View, Horizontal: 91.5°
- Lens Angle of View, Vertical: 46.1°
- Lens Angle of View, Diagonal: 109.6°
- Pitch Angle: 0 - 90°
- Shutter Speed: 1/3 to 1/10000
- Drilling template included: Yes
- Number of cameras: 1
- Form factor: Turret
- Mounting type: Ceiling
- International Protection (IP) code: IP67
- Weatherproof: Yes
- Protection features: Water resistant
- Housing material: Metal
- Night vision: Yes
- LED type: Infrared/White
- Dynamic range: 120 dB
- Type: CCTV security camera
- Supported placement: Outdoor
- Connectivity technology: Wired
- Day/Night mode: Yes
- Remote viewing: Yes
- IR cut filter: Yes
- Wide dynamic range (WDR): Yes
- Plug and play: Yes
- Maximum operating distance: 107 m
- Signal-to-noise ratio (SNR) (panoramic camera): 52 dB
- Sensor type (panoramic camera): CMOS
- Digital wide dynamic range (DWDR) (panoramic camera): Yes
