Alantec GN002 RJ45 conector

ALANTEC GN002 Toolless Shielded RJ45 Connector for Cat.6A Networks

Achieve professional-grade, high-performance network terminations in record time with the ALANTEC GN002 RJ45 Connector. Engineered for speed, reliability, and ultimate convenience, this connector is the definitive solution for field installations and network upgrades where performance cannot be compromised. It empowers technicians, installers, and even advanced DIY enthusiasts to create flawless, high-bandwidth connections for network cables without the need for specialized crimping tools, dramatically reducing installation time and eliminating common points of failure associated with traditional plugs.

The core benefit of the GN002 lies in its innovative toolless design. This system simplifies the termination process to a few intuitive steps, ensuring a perfect, secure connection every single time. By eliminating the crimping tool, you not only streamline your workflow but also reduce the gear you need to carry on-site. Its robust, reusable construction means that wiring mistakes can be corrected quickly and easily without wasting a connector, making it a cost-effective and environmentally conscious choice for any project.

Designed to meet and exceed the stringent demands of modern high-speed networks, the ALANTEC GN002 is fully compliant with the Cat.6A standard. This ensures flawless support for 10 Gigabit Ethernet (10GbE) applications, providing the bandwidth necessary for data-intensive tasks, streaming ultra-high-definition media, and supporting next-generation enterprise and data center infrastructures. Its fully shielded metal housing provides superior protection against electromagnetic interference (EMI) and radio frequency interference (RFI), guaranteeing signal integrity and a stable, noise-free connection. This is especially critical in electrically noisy environments and for powering devices using Power over Ethernet (PoE, PoE+, and PoE++), where stable data transmission is paramount.

Main Features:

* Exceptional performance compliant with Category 6A standards for 10 Gigabit Ethernet.
* Fully shielded construction for outstanding protection against external interference and crosstalk.
* Intuitive, color-coded wiring guide (T568A/T568B) for fast and error-free termination.
* Robust and durable housing provides excellent strain relief and protects the connection point.
* Reusable design allows for easy correction of wiring errors without connector loss.
* Optimized for on-site field termination of custom-length network patch cords.
* Broad compatibility with various shielded cable types within its specified range.

Tools

The ALANTEC GN002 features a toolless termination mechanism. No specialized crimping tool is required for assembly. Basic tools such as a wire stripper and cutter are sufficient to prepare the cable for insertion into the connector´s intuitive wire management system.

Technical Specifications
* Model: GN002
* Category: Cat.6A
* Shielding: Fully Shielded (FTP/STP)
* Supported Bandwidth: Up to 500 MHz
* Housing Material: Die-Cast Zinc Alloy
* Conductor Compatibility: Solid or Stranded Wire
* Wire Gauge Compatibility: AWG 22 to AWG 26
* Cable Diameter Compatibility: 6.0 mm to 9.0 mm
* Contact Plating: Gold Plating for superior conductivity and corrosion resistance
* Mating Cycles: ≥ 750
* PoE Compliance: IEEE 802.3af (PoE), 802.3at (PoE+), and 802.3bt (PoE++)
* Standards Compliance: ISO/IEC 11801, ANSI/TIA-568-C.2
* Operating Temperature Range: -40°C to +80°C
