Amass AM-XT90-PS Adapter

AMASS AM-XT90-PS Adapter | Secure Panel Mount Power Connector

Elevate your high-power projects with the AMASS AM-XT90-PS Adapter, the definitive solution for creating a secure, reliable, and professional-grade power interface. Engineered for demanding applications within the Devices and Connectivities space, this adapter provides an unparalleled combination of safety, performance, and integration ease. It is meticulously designed to serve as a robust bulkhead or panel-mounted power socket, allowing for clean and stable connections directly on your chassis, enclosure, or power distribution board. Move beyond unsecured, dangling wires and establish a fixed, dependable power point for batteries, power supplies, and high-draw components. The AM-XT90-PS ensures a solid, unyielding connection, minimizing voltage drop and maximizing power transfer efficiency, which is critical for performance-driven systems like large-scale drones, robotics, electric vehicles, and custom battery packs.

The core benefit of the AMASS AM-XT90-PS lies in its ability to transform a potentially hazardous, messy connection into a safe and streamlined interface. The sheathed design of the solder terminals provides essential protection against accidental short circuits during and after installation, a crucial safety feature when working with high-capacity lithium batteries. Its design guarantees a firm, positive-locking fit with any standard XT90 connector, eliminating the risk of disconnection due to vibration or shock—a common point of failure in mobile and high-vibration environments. By providing a stable mounting point, it also significantly reduces mechanical stress on solder joints and wires, extending the lifespan and reliability of your entire electrical system. This adapter is the professional’s choice for building durable, serviceable, and safe high-current power systems.

Main Features
* Integrated Panel Mount design for secure, flush installation on enclosures
* Engineered for exceptional high-current and high-voltage performance
* Sheathed rear solder terminals to prevent accidental short circuits
* Low-resistance gold-plated contacts for maximum power transfer efficiency
* Ensures a secure, positive-locking connection to prevent accidental disconnects
* Ergonomically designed for easy and reliable mating and de-mating cycles
* Robust construction for long-term durability and performance

Technical Specifications
* Product Model: AM-XT90-PS
* Attribute: Adapters
* Instantaneous Current: 90A
* Rated Current: 40A
* Rated Voltage: DC 500V
* Contact Resistance: 0.30mΩ
* Recommended Wire Gauge: 8AWG / 10AWG / 12AWG
* Operating Temperature Range: -20°C to 120°C
* Mechanical Life: Up to 1000 insertion/extraction cycles
* Mounting Style: Panel Mount / Chassis Mount with screw holes
