Blackmagic Design HyperDeck Studio HD Plus Video Mixer

BLACKMAGIC DESIGN HyperDeck Studio HD Plus Video Mixer

Elevate your production workflow to broadcast standards with the BLACKMAGIC DESIGN HyperDeck Studio HD Plus. More than just a recorder, this advanced broadcast deck is a comprehensive solution for professional recording, playback, and media management, making it an indispensable tool for live production, broadcast, and AV professionals.

EU PLUG.

Blackmagic Design´s HyperDeck Studio HD Plus Video Mixer Black is a versatile video recorder and playback system that offers professional-grade Features to photographers and videographers.

The device Features a built-in 7-inch LCD touchscreen that makes it easy to navigate through menus and view content on the device.

The HyperDeck Studio HD Plus Video Mixer Black is perfect for live video production, event recording, and post-production.

Its 12G-SDI and HDMI inputs and outputs ensure all your footage is captured in the highest quality possible.

Additionally, this video mixer is packed with advanced Features like timecode support, SDI and HDMI output conversion, and 10-bit SDI and HDMI video playback.

The HyperDeck Studio HD Plus Video Mixer is an essential accessory for any photographer or videographer looking for high-quality recording and playback.



Designed with a modern, intuitive interface, the HyperDeck Studio HD Plus combines the reliability of a traditional deck with the flexibility of modern file-based workflows. It records high-quality video files directly onto common SD cards, UHS-II cards, or external USB-C disks, providing cost-effective and readily available media options. The dual media slots allow for non-stop recording; when one card is full, recording automatically continues on the next, ensuring you never miss a moment of critical action.

This model is a powerhouse of connectivity and professional features. It supports recording in a range of professional codecs including H.264, ProRes, and DNxHD, providing the perfect balance between file size and image quality for any application, from immediate web distribution to high-end post-production. The support for HDR workflows and 3D LUTs allows for advanced color management and monitoring, ensuring your creative vision is perfectly captured and displayed.

The integrated timecode and sync generator makes the HyperDeck Studio HD Plus the cornerstone of any multi-camera setup. You can stack multiple units to create a perfectly synchronized recording and playback environment, drastically simplifying your editing process. Furthermore, its ability to output a signal with a fill and key channel makes it ideal for broadcast graphics and presentations, adding another layer of professional capability to your productions.

Attributes:

* Type: Mixers

Technical Specifications:

* SDI Video Connections: 1x6G-SDI Input, 2x6G-SDI Outputs
* HDMI Video Connections: 1 x HDMI 2.0 Input, 1 x HDMI 2.0 Output
* Built-in Speaker: Monaural
* Audio Output: 1x6.35 mm headphone jack
* Screen: 7-inch LCD with 1920x1200 resolution
* Timecode Connections: 1 x BNC Input, 1 x BNC Output
* Reference Connections: 1 x BNC Input, 1 x BNC Output (Tri-Sync or Black Burst)
* Media: 2 x SD card slots, 1 x USB-C 3.0 Gen 1 expansion port for external recording
* Computer Interface: 1 x USB-C 3.0 for software updates, control, and webcam output
* Ethernet: 1Gb/s for file transfer, control, and software updates
* Supported Codecs: ProRes, DNxHD, H.264 (up to 10-bit 4:2:2 in all formats)
* Built-in Monitoring: Waveform, Vectorscope, RGB Parade, and Histogram scopes
* HDR Support: Hybrid Log-Gamma, ST2084 300, ST2084 500, ST2084 800, ST2084 1000, ST2084 4000
* Power Supply: 1 x Internal 100 - 240 AC, 1x4-pin XLR 12V DC input
