Chieftec Value APB-400B8 Power Supply

CHIEFTEC Value APB-400B8 400W ATX Power Supply

Discover the ideal balance of reliability, efficiency, and performance with the CHIEFTEC Value APB-400B8 Power Supply. Engineered for modern office and home computer systems, this 400 W PSU delivers stable and consistent power to ensure your components operate at their best. As part of CHIEFTEC’s esteemed VALUE series, the APB-400B8 is a testament to quality engineering, offering a smart and dependable solution for system builders and upgraders who demand stability without compromise. Its standard ATX form factor guarantees broad compatibility with a wide range of PC cases, making it a versatile choice for new builds or as a replacement unit. The non-modular design simplifies installation, providing all the essential connections you need in a straightforward, ready-to-use package.

Key Benefits of the CHIEFTEC APB-400B8

Experience enhanced system stability and peace of mind with a power supply built for endurance. The APB-400B8 is designed for high efficiency, leading to reduced energy consumption, lower operational costs, and less waste heat. This not only contributes to a greener footprint but also helps maintain lower internal system temperatures. Operation is remarkably quiet, thanks to a large, temperature-controlled fan that adjusts its speed automatically, ensuring optimal cooling with minimal noise. Furthermore, a comprehensive suite of built-in safety protections actively safeguards your valuable PC components against common electrical risks like power surges and short circuits, providing a secure and reliable computing environment.

Main Features
* ATX 12V 2.3 standard for wide system compatibility
* Active Power Factor Correction (PFC)
* Efficiency rating of >80%
* Low-noise 120mm fan for quiet operation
* Automatic Fanspeed Control (AFC)
* Under Voltage Protection (UVP)
* Over Voltage Protection (OVP)
* Short Circuit Protection (SCP)
* Over Power Protection (OPP)
* Fixed, non-modular cables for easy setup

Technical Specifications

Model: APB-400B8
Power: 400 W
Efficiency: >80%
Input Voltage: 230V / 50Hz
Security: UVP, OVP, SCP, OPP, AFC
Certificates: CE, TÜV, EAC

DC Output:

* +3.3V: 18 A
* +5V: 15 A
* +3.3V & +5V combined: 110 W
* +12V1: 15 A
* +12V2: 15 A
* +12V combined: 348 W
* -12V: 0.3 A (3.6 W)
* +5Vsb: 2.5 A (12.5 W)
* Total Power: 400 W

Connectors:

* 1x 20+4 PIN ATX
* 1x 4+4 PIN CPU
* 3x SATA
* 2x MOLEX (IDE)
* 1x FLOPPY

Dimensions (DxWxH): 140 mm x 150 mm x 87 mm
