Conspit ARES 20 Servo Base

CONSPIT ARES 20 Servo Base: The Apex of Direct Drive Racing Immersion

Unleash the ultimate in racing realism with the CONSPIT ARES 20 Servo Base, the definitive core for your professional-grade simulator setup. Engineered for the most discerning PC sim racers, this direct drive system delivers an unparalleled connection between you and the virtual track. Experience every subtle texture of the asphalt, feel the precise limit of traction through tight corners, and react with the lightning-fast precision demanded by competitive motorsports. The ARES 20 is meticulously crafted not just to simulate racing, but to transport you directly into the driver´s seat for a truly visceral experience.

At the heart of the ARES 20 is a custom-developed, industrial-grade servo motor capable of producing a formidable 20 Nm of sustained peak torque. This immense power translates into incredibly dynamic and detailed force feedback that is both powerful and nuanced. The direct drive design ensures zero-latency and zero cogging, transmitting the FFB signal from the PC to your hands instantaneously. You will feel the weight transfer of the car, the slip of the tires, and the impact of every kerb with unfiltered clarity. This high-fidelity feedback provides the critical information needed to push your vehicle to its absolute limit, lap after lap.

Built for endurance and peak performance, the entire housing of the ARES 20 is precision-milled from a single block of aviation-grade aluminum. This robust unibody construction not only provides a premium aesthetic but also acts as a massive heatsink, managed by an intelligent temperature control system. This ensures your force feedback remains powerful and consistent, even during the most grueling endurance races, preventing performance degradation due to heat. The system also features a revolutionary wireless power supply and data transmission system for compatible CONSPIT steering wheels, eliminating coiled cables for a cleaner, more reliable, and professional cockpit.

Main Features
* Direct Drive Servo Motor Technology
* 20 Nm Sustained Peak Torque
* CNC Milled Aviation-Grade Aluminum Unibody Housing
* Proprietary Wireless Power and Data Transmission for Steering Wheels
* Intelligent Active Temperature Control System for Consistent Performance
* Ultra-Low Latency for Instantaneous Response
* Ultra-High Resolution Encoder for Supreme Positional Accuracy
* Multiple Driving Modes (Race, Drift, Custom)
* Fully Adjustable Settings via CONSPIT Link Software Suite

Technical Specifications
* Platform: PC
* Drive System: Direct Drive
* Peak Torque: 20 Nm
* Housing Material: Aviation-Grade Aluminum Alloy, CNC Machined
* Wheel Connectivity: Wireless Power & Data Protocol
* PC Connectivity: USB-B
* Encoder Resolution: 262144 ppr (18-bit)
* Input Voltage: 100-240V AC
* Peak Power: 480W
* Mounting: 4-Hole Bottom Mount Pattern (M8)
