Elo Touch E388675 15´´ VESA Mount

Elo´s I-Series for Windows delivers commercial-grade computing with the capabilities, security and enterprise infrastructure of a powerful, Windows-based platform—all in a sleek, yet durable fixed tablet form factor.

Built on a modular platform and available with either 15-inch or 22-inch displays, the I-Series for Windows can be found in installations across the globe, from in-store interaction and point-of-sale to self-service, hospitality and corporate office environments.

The uses are virtually unlimited.

Features:

Configure with Elo Edge Connect™:

- Built with versatility in mind, the Elo Edge Connect system offers a wide assortment of peripherals that seamlessly attach to the edge of the touchscreen.

And you can add or swap them out later as your needs change.

Windows or Linux.

You Choose:

- Elo´s I-Series utilizes the reliability-tested performance and security of Intel´s 8th-generation processors and vPro™ platform.

Available with Windows 10 or, for added flexibility, the I-Series offers models with no OS-all pretested with Linux SuSE, Ubuntu and Red Hat operating systems-allowing businesses to get the solution best suited for them.

Get Peace of Mind With EloCare℠:

- EloCare is service and support from the people who know your Elo products best.

From extended warranties and on-site exchange to advance unit replacement and field services, the highly skilled Elo technical specialists will get you up and running.

Specifications:

- Touch Technology & Capacity:

PCAP (TouchPro® Projected Capacitive).

- 10 Touch Processor:

- Celeron:

Intel® Celeron® J4105 Processor (4M Cache, up to 2.5 GHz).

- I3:

Intel Core™ i3-8100T Processor (6M Smart Cache, 3.10 GHz).

- I5:

Intel Core i5-8500T Processor (9M Smart Cache, up to 3.50 GHz by Intel Turbo Boost Technology 2.0) with Intel vPro™ Support Chipset:

- Celeron:

N/A.

- I3:

Intel H310 Express.

- I5:

Intel Q370 Express Graphics:

- Celeron:

Intel UHD Graphics 600.

- I3 & i5:

Intel UHD Graphics 630.

- Bios:

Ami Memory (Ram):

- Celeron:

4GB 2666MHz DDR4 SO-DIMM on 1 of 2 slots (Expandable to 8GB maximum on 2 slots).

- Note:

Maximum memory using 2 slots.

Expandable up to 8GB maximum, SO-DIMM DDR4-2666.

Check brand of the memory included in your unit before purchasing the memory kit.

- I3 & i5:

8GB 2666MHz DDR4 SO-DIMM on 1 of 2 slots (Expandable to 32GB maximum on 2 slots).

- Note:

Maximum memory using 2 slots.

Expandable up to 32GB maximum, SO-DIMM DDR4-2666.

Check brand of the memory included in your unit before purchasing the memory kit.

Storage:

- 128GB M.2 SATA SSD 72 Tbw.

- Gb equals one billion bytes when referring to storage capacity.

Accessible capacity may be less.

- TPM:

2.0.

- Active Management Technology (Amt):

Celeron:

N/A.

- I3 & i5:

Active Management Technology (Intel Amt 11.0) Support.

- Diagonal Size:

15.6´´ diagonal, Active matrix Tft Led (Led).

- Aspect Ratio:

16:9.

- Active Area (mm):

13.55´´ x 7.62´´ / 344.2 mm x 193.5 mm Resolution:

1920 x 1080 60Hz Number of Colors:

266,144 Brightness (typical) LCD panel:

300 nits TouchPro PCAP:

270 nits Response Time-total (typical):

25 msec.

- Contrast Ratio:

700:1.

- Viewing Angle:

Horizontal:

±80° or 160° total / Vertical:

±80° or 160° total.

- Usb Ports:

1 x USB 3.0.

- 4 x Micro USB 2.0 on edges for optional Elo Edge Connect peripherals.

- Ethernet Port:

1 x LAN RJ45 (Gigabit).

- Wireless:

Wi-Fi 802.11 a/b/g/n/ac 2.4GHz and 5GHz.

- Bluetooth:

Bluetooth 5.0.

- Audio Ports:

1 x 3.5mm line out.

- Speakers:

2 x 2W internal speakers OS:

No OS.

- Windows 10 IoT Enterprise LTSC 64-bit.

- Optional.

- Windows 10 Professional English 64-bit.

- Languages:

Windows 10.

- 36 Language groups Power Supply:

- External Usb-C power supply brick.

- AC input voltage:

100-240 VAC.

- Input frequency:

50-60 Hz.

- Maximum output power:

100W Power Consumption (Typical):

- Celeron:

30 W.

- I3:

67 W.

- I5:

73 W.

- Dimensions:

15.13´´ x 9.7´´ x 1.72´´ / 384.2 mm x 246.4 mm x 43.8 mm.

- Shipping Box Dimensions:

18.19´´ x 8.5´´ x 13.57´´ / 462 mm x 216 mm x 346 mm.

- Weight (Unpackaged):

4.9 lbs / 2.2 kg.

- Weight (Packaged):

9.5 lbs / 4.3 kg.

- Operating Temperature:

0°C to 35°C / 32°F to 95°F.

- Storage Temperature:

-20°C to 60°C / -4°F to 140°F Humidity:

- Operating:

20% to 80%.

- Storage:

5% to 95% (38.7°C max wet bulb temperature) Regulatory approvals and declarations:

- UL/cul, Fcc, Tuv, CE, CB, Mexico Nom, C-Tick/Rcm, Vcci, Argentina S-Mark, ccc.

- Real-Time Clock:

CR2032 lithium metal battery.

- Mtbf:

50,000 hours demonstrated.

- Mounting Options:

75mm Vesa mount Sealability:

- Touchscreen sealed to sub-bezel.

- Touchscreen sealed to Lcd.

- Power Cables:

North American and European power cables included Other.

Features:

- Serviceable internal components.

- Kensington lock What´s in the Box:

- I-Series 2.0 for Windows Touchcomputer.

- North America Power Cord.

- European Power Cord.

- Power Adapter.

- 100W.

- Cable cover locking screw.

- Quick Install Guide.
