Engel AN6000G5 MAX42 DTT decoder

ENGEL AN6000G5 MAX42 DTT Central Amplifier

Experience Flawless, Crystal-Clear Television in Every Room

Transform your home´s television viewing experience with the ENGEL AN6000G5 MAX42, a professional-grade DTT central amplifier designed for superior signal quality and distribution. Say goodbye to pixelated images, lost channels, and frustrating interference. This powerful device is the ultimate solution for homes in areas with weak or challenging terrestrial TV signals, ensuring you receive a stable, high-definition picture on every television connected to your system. Engineered with cutting-edge technology, the AN6000G5 MAX42 is built to combat modern signal challenges and deliver uncompromising performance.

The standout benefit of this central amplifier is its integrated 5G filter. As mobile networks expand, interference from 5G signals can disrupt your DTT reception. The AN6000G5 proactively blocks these unwanted frequencies, safeguarding your channels and providing an uninterrupted, clean signal. Coupled with an exceptionally high gain of up to 42 dB, this amplifier can capture and significantly boost even the faintest of signals, making it ideal for rural locations, buildings with complex wiring, or installations with long cable runs.

Key Benefits:

* Interference-Free Viewing: The built-in high-rejection 5G and LTE filter eliminates signal disruption from mobile phone towers, ensuring a stable and reliable picture.
* Exceptional Signal Amplification: With a powerful maximum gain of 42 dB, it dramatically improves reception in areas with weak signals, restoring lost channels and enhancing picture clarity.
* Full Home Coverage: Designed as a central distribution amplifier, it provides a consistently strong signal to multiple televisions throughout your home from a single unit.
* Customizable Signal Management: Independent gain regulation for each input allows for precise balancing of different signal sources, optimizing the performance of your entire antenna setup.
* Professional-Grade Reliability: Constructed with a robust Zamak chassis, it offers maximum shielding against electromagnetic interference and ensures long-lasting durability.

Main Features:

* High-Gain Central Amplifier for Digital Terrestrial Television (DTT)
* Advanced Integrated 5G and LTE Filtering Technology
* Multiple Inputs for Comprehensive Antenna System Integration
* Independent and Adjustable Gain Control for Each Input Band
* High Output Level to Feed Extensive Coaxial Networks
* Low Noise Figure for a Cleaner, Sharper Signal
* Integrated Power Supply Unit for Simple Installation
* ON/OFF Switch for DC Power Passthrough to Feed Active Antennas

Antennas and System Integration

The ENGEL AN6000G5 MAX42 serves as the heart of your home´s terrestrial television system, positioned between your rooftop Antennas and your televisions. It is designed to process and amplify signals from various antenna types, including UHF and VHF. The unit features multiple inputs, allowing you to combine signals from different antennas pointing at separate transmitters. Furthermore, its switchable DC power passthrough feature enables it to supply power directly to active antennas or masthead preamplifiers, simplifying your installation and eliminating the need for separate power injectors.

Technical Specifications:

* Inputs: 3 (FM / VHF / UHF)
* Frequency Range: 47-68 MHz (FM), 174-230 MHz (VHF), 470-694 MHz (UHF)
* Gain: 30 dB (FM), 40 dB (VHF), 42 dB (UHF)
* Gain Regulation: 20 dB (FM/VHF), 16 dB (UHF)
* Noise Figure: 5 dB (VHF), 4 dB (UHF)
* Output Level (DIN 45004B): 118 dBµV
* 5G/LTE Filter Rejection: >20 dB @ 694 MHz
* Power Supply: 230 VAC, 50/60 Hz
* Power Consumption: 6 W
* DC Passthrough: 12 VDC / 50 mA (Switchable)
* Connectors: F-Type
* Chassis Material: High-Shielding Zamak
