Equip 8K 10 m DisplayPort cable

The equip® DisplayPort Cable is a digital audio and video cable, designed primarily for connections between computer and its display monitor, or a computer and a home-theater system. Intended to replace VGA, DVI and HDMI cables, By supporting a maximum bandwidth of 32.4 Gbps, content up to 8K Ultra HD (7680 x 4320 @ 60 Hz) resolution can be displayed.


Features:

- DisplayPort Male to Male
- Supports video resolutions up to 8K/60Hz, 4K/120Hz
- Gold Plated Connectors for high signal quality
- Downwards compatible to DisplayPort 1.1, 1.2 and 1.3
- Transmission of audio and video signals
- Compliant with VESA certified
- DisplayPort DP 8K certified cable
- Bandwidth up to 32.4Gbps
- Supports HDCP 1.4 and 2.2
- Supports HDR (High Dynamic Range)
- Supports DSC (Display Stream Compression)
- Supports MST (Multi Stream Transport)
- Resolution up to below (depend on system and connector hardware)


Specifications:

Miscellaneous:
- Max. Resolution: 8K/60Hz
- Connector 1: DisplayPort, male
- Connector 2: DisplayPort, male

Others:
- Approval and Compliance: CE , RoHS

System specifications::
- Bandwidth: 32.4Gbps
- Conductor material: Copper
- Conductor size (AWG): 26AWG
- DisplayPort version: 1.4
- Cable Jacket material: PVC
- Standards: DisplayPort 1.4

Physical Specifications:
- Cable Length: 10m
- Dimensions (W x D x H): 10000 x 20 x 13 mm
- Product weight (kg): 0.55

Data transfer without DSC (display stream compression):
- 8k: 7680 x 4320 @ 30 Hz.

Data transfer with DSC support. (display stream compression):
- 8k: 7680 x 4320 @ 60 Hz (DSC).

Package Contents:
- DisplayPort 1.4 Cable
