Features of Level one AC750

Product description of Level One AC750 WIFI Access Point

Description summary

EU Plug.

LevelOne´s WAP-8121 is a managed, dual-band wireless access point, capable of a combined speed of up to 750 Mbps.

The device runs on 2.4 and 5 GHz frequencies, and can be used as part of a managed network when controlled by the LevelOne WAC-2000/WAC-2003 Wireless LAN Controller.

LevelOne WAP-8121 also offers PoE, removing the need for an external power supply, which makes it easy to install.

A fast, versatile and secure access point for a wide variety of network requirements.

Features:

- Share your wireless network up to 750Mbps.

- Compatible with IEEE 802.11a/b/g/n/ac wireless standards.

- Provides up to 8 SSIDs to separate network traffic and enhance security.

- Multi-operation modes to suit different wireless applications.

- Auto Channel Selection for low interference band.

- Dual power support:12V DC/PoE (IEEE 802.3at).

Specifications:

- Data rate:802.11AC:433.3 Mbps 802.11n:300 Mbps 802.11g:54 Mbps 802.11b:11 Mbps 802.11a/g:54 Mbps.

- Power Consumption:15W.

- Approval and compliance:CE.

- Max.

operating humidity (%):90.

- Max.

operating temperature (°C):50.

- Max.

storage humidity (%):90.

- Max.

storage temperature (°C):70.

- Min.

operating humidity (%):10.

- Min.

operating temperature (°C):-20.

- Min.

storage humidity (%):5.

- Min.

storage temperature (°C):-40.

- Antenna:1 x 5GHz 5dBi internal Omni antennas 2 x 2.4GHz 5dBi internal Omni antennas.

- Button:Reset.

- EIRP(dBm):2.4GHz / 5GHz:- Encryption:WEP 64/128-bit Web share key encryption WPA, WPA2 128-bit TKIP/AES encryption WPA, WPA2-PSK TKIP/AES encryption.

- Frequency band:2.4 ~ 2.4835 GHz 5.15 ~ 5.35 GHz 5.46 ~ 5.72 GHz 5.725~ 5.825 GHz Indicators:- Power.

- WiFi.

- RAM size:128MB (DDR2).

- Flash memory size:16MB.

- Mount:Ceiling mount.

- Operating modes:Gateway Mode, Repeater Mode, AP Mode, WISP Mode.

- Power supply:Power adapter (ordered separately).

Processor:Qualcomm QCA9531 + QCA9887 Standards:- IEEE 802.3 10-BASE-T, Ethernet.

- IEEE 802.3u 100-BASE-TX, Fast Ethernet.

- IEEE 802.11e Wi-Fi Multimedia (WMM).

- IEEE 802.3x Ethernet Flow Control.

- IEEE 802.11i Wi-Fi Protected Access (WPA2).

- IEEE 802.11a,IEEE 802.11b, IEEE 802.11g, IEEE 802.11n,.

- IEEE 802.11AC.

- IEEE802.3at Power over Ethernet is recommended.

- Wireless channels:2.4GHz:Ch.1 ~ 13 EU Ch.1 ~ 11 USA 5GHz:Ch.36 ~ 48 EU Ch.36 ~ 48, 149 ~ 161 USA.

- General.

Features:

Multi-SSID:8 SSIDs (2.4GHz x 4 SSIDs + 5.8GHz x 4 SSIDs).

- Product weight (kg):0,326.

- Product breadth (mm):189.

- Product depth (mm):38,5.

- Product height (mm):189 Package contents:- Schraubenset.

- RJ45-Ethernet-Kabel.

- Quick Installation Guide.

- Ressource CD (Bedienungsanleitung, QIG).

- Fast Ethernet RJ45:2.

- 802.3af/at PoE:1 Receiver sensitivity:2.4GHz:- 802.11n (20MHZ):Range (-70) dBm.

- 802.11n (40MHZ):Range (-68 ) dBm.

- 802.11g:Range (-72) dBm.

- 802.11b:Range (-95) dBm 5GHz:- 802.11ac (80MHZ):Range (-62) dBm.

- 802.11ac (40MHZ):Range (-65) dBm.

- 802.11ac (20MHZ):Range (-68) dBm.

- 802.11n (40MHZ):Range (-68 ) dBm.

- 802.11n (20MHZ):Range (-70) dBm.

- 802.11a:Range (-72) dBm.

- Frequency band:2.4/5GHz(Dual bands).

- Max.

Wi-Fi Data Rate:750Mbps.

- Wireless AP Type:Ceiling.

- PoE Supported:Yes.
