Panduit PSF2PZC5MBL cable

The high speed twin-axial cable assembly features SFP28 25Gig hot pluggable modular connectors on each end. It is black and 5 meters in length.


Specifications:

- Jacket Material: PVC
- Conductor Gauge (AWG): 26
- Connector 1 Type: SFP28
- Connector 2 Type: SFP28
- Overall Length (ft.): 16.4
- Overall Length (m): 5
- Nominal Diameter (In.): 0.343
- Nominal Diameter (mm): 8.7
- Bend Radius (In.): 1.715
- Bend Radius (mm): 43.5
- Number of Connector 1 Ports: 1
- Number of Connector 2 Ports: 1
- Maximum Operating Temperature (°C): 80
- Maximum Operating Temperature (°F): 176
- Minimum Operating Temperature (°C): -25
- Minimum Operating Temperature (°F): -13
- Data Transfer Rate (Gb/s): 25
- Resistance Properties: Flame-Resistant
- Standards Met: Compliant to SFF-8431, SFF-8432 and SFF-8472, IEC flame compliance: IEC 60332, 60333, 60324, CE and RoHS Compliant
- Part Features: 100% performance tested, robust construction, low latency performance, passive low power assembly, low profile, small diameter cable design, built-in strain relief, variety of lengths and a variety of colors
