Qnap TS-932PX NAS

The 1.7GHz quad-core TS-932PX supports nine drive bays in the size of a 5-bay NAS.

With five 3.5´´ SATA 6Gb/s drive bays and four 2.5´´ SATA 6Gb/s drive bays, the TS-932PX provides the ability to create a hybrid HDD/SSD infrastructure for improved performance.

of the applications.

With two 10GbE SFP+ and two 2.5GbE LAN ports, the TS-932PX supports next-generation networking to enable high-bandwidth applications and offer smoother file access and sharing.

Energy-efficient quad-core processor.

Equipped with a 1.7 GHz quad-core 64-bit ARM Cortex-A57 processor and 4 GB of DDR4 RAM (expandable to 16 GB), the TS-932PX has very low consumption without affecting system performance or of the applications.

High-speed connectivity at 10GbE and 2.5GbE.

The TS-932PX includes two 10GbE SFP+ and two 2.5GbE RJ45 LAN ports, offering out-of-the-box support for high-speed networks and Port Trunking and Failover to strengthen your infrastructure.

network.

QNAP also offers many other high-speed networking solutions, including 10GbE/2.5GbE managed/unmanaged switches and network adapters, allowing you to create an affordable high-speed networking environment.

Improve NAS performance with 2.5´´ SATA SSD.

SSDs can significantly improve NAS performance without requiring a large investment.

The TS-932PX supports SSD caching technology, Qtier automatic tiering, and SSD over-provisioning, helping you balance storage performance, storage allocation, and IT expenses.

Protect your important data with snapshots.

Snapshots record the metadata and system state of the NAS and can be used to quickly restore files to previously recorded states if they are accidentally deleted/modified or if the system is compromised by a ransomware attack.

QNAP snapshots are block-based and only record modified data.

This not only saves storage space, but also reduces the time needed to backup or restore data.

The TS-932PX supports up to 256 snapshots per NAS and a maximum of 64 snapshots per volume or LUN.

Backup, access and sync files from multiple points.

The TS-932PX supports common file sharing protocols (including SMB/CIFS, AFP, and NFS) for Windows, Mac, and Linux/UNIX devices.

Combined with Qsync (a tool that turns QNAP NAS into a secure, high-capacity data center for file synchronization), files uploaded to the TS-932PX will be available to all connected devices, such as computers, laptops, etc.

and mobile devices.

Hybrid Backup Sync helps you easily backup or sync TS-932PX files to other QNAP NAS, remote server or cloud storage (including Microsoft One Drive, Google Drive and Dropbox) for easy disaster recovery.

AI-based smart photo management.

QuMagie integrates QuMagie Core´s AI-based image recognition technology for facial recognition, subject identification, and photo geotagging.

Photos are categorized into People, Places, and Things albums.

QuMagie also includes built-in timeline scrolling, customizable folder covers, iOS Live Photos viewing, and an advanced search tool to deliver the most innovative photo management and sharing solution.

Low latency access to cloud data thanks to cloud storage gateways.

By implementing cloud storage gateways and enabling local caching on the TS-932PX, you can use the cloud for data storage, backup, and recovery with low-latency access, delivering an innovative hybrid cloud experience.

Easily search and automatically organize files.

The TS-932PX offers greater convenience for file management.

You can quickly find files using Qsirch and automatically archive them with Qfiling.

Secure remote access to your QNAP NAS.

Use myQNAPcloud Link to access, share, download and manage files stored on a NAS located at headquarters over the Internet.

The QNAP NAS also supports VPN services so that remote employees can access the NAS and resources on a private network from the Internet.

You can also use the QVPN Device Client equipped with QNAP´s own QBelt protocol to easily connect to your TS-932PX and use measurement tools to know the speed of your VPN connections and connection history.

Specifications:-Processor manufacturer:Annapurna Labs.

-Processor family:Annapurna Labs.

-Processor frequency:1.7 GHz.

-Number of processor cores:4.

-Processor model:Alpine AL-324.

-Processor architecture:ARM Cortex-A57.

-Internal memory:4 GB.

-Internal memory type:DDR4.

-Maximum RAM supported:16 GB.

-Flash Memory:512 MB.

-Memory slots:1.

-Memory factor form:SO-DIMM.

-Ethernet LAN ports (RJ-45):2.

-USB port:Yes.

-USB 3.2 Gen 1 (3.1 Gen 1):3.

-Fiber Channel ports:2.

-Fiber optic connector:SFP+.

-Width:224.6 mm.

-Depth:224.1 mm.

-Height:182.7 mm.

-Weight:3.39 kg.

-Package weight:4.99 kg.

-Power Supply Location:External.

-Power supply capacity (PSU):120 W.

-Number of power supplies:1.

-AC input voltage:100 -240 V.

-Fan voltage:12 V.

-Operating temperature range:0 -40 °C.

-Relative operating humidity:5 -95%.

-Ethernet:Yes.

-Ethernet LAN, data transfer speed:100,1000,2500,10000 Mbit/s.

-DHCP, client:Yes.

-DHCP, server:Yes.

-Jumbo Frames, support:Yes.

-Network connection:Yes.

-WLAN adapter compatibility:Yes.

-iSCSI support:Yes.

-Adding links:Yes.

-Supported network protocols:FTP, SFTP, TFTP, ec, OpenVPN, QBelt.

-Dynamic DNS:Yes.

-Automatic load control:Yes.

-Supported LAN Ethernet data rate (max.):10000 Mbit/s.

-Storage units installed:No.

-Type of storage units installed:No.

-Types of storage units supported:HDD & SSD.

-Number of supported storage units:9.

-RAID compatibility:Yes.

-Hot-swap drive receptacles:Yes.

-Supported storage disk interfaces:Serial ATA III.

-Supported disk storage sizes:2.5,3.5´´.

-Supported file systems:FAT32,HFS+,NTFS,ext3,ext4.

-RAID levels:0,1,5,6,10,50,60,JBOD.

-Online RAID level migration:Yes.

-Online RAID expansion:Yes.

-RAID reconstruction:Yes.

-Detection of damaged sectors:Yes.

-Disk roaming:Yes.

-Installed operating system:QNAP Turbo System.

-Supported Windows operating system:Windows 10, Windows 7, Windows 8.

-Supported Linux operating system:Yes.

-Supported MAC operating system:Mac OS X 10.10 Yosemite,Mac OS X 10.11 El Capitan,Mac OS -Supported server operating system:Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016,Windows Server 2019.

-Operating system version:4,4,2.

-External power adapter:Yes.

-Chassis type:Tower.

-Cooling type:Active.

-Product color:Black.

-Number of fans:1 Fan(s).

-Fan diameter:14 cm.

-LED indicators:HDD, LAN, SSD, Status, USB.

-Security cable slot:Yes.

-Cable lock slot type:Kensington.

-Type:NAS.

-Device class:Small and medium-sized businesses.

-Backup function:Yes.

-Backup options:Cloud, iSCSI LUN.

-Vibrator:Yes.

-Multilingual support:Yes.

-Noise level:18.6 dB.

-Instant image:Yes.

-Supported security algorithms:256-bit AES,FIPS 140-2,HTTPS,SNMPv2,SNMPv3,SSH,SSL/TLS.

-Built-in FTP server:Yes.

-Compatible browser:Apple Safari 7+, Google Chrome, Microsoft Internet Explorer 10+, Mozilla Firefox.

-System registration:Yes.

-Hot replacement:Yes.

-SMART Support:Yes.

-Share folder:CIFS/SMB.

-USB copy function:Yes.

-Access Control List (ACL):Yes.

-Web-based administration:Yes.

-Restore button:Yes.

-Integrated on/off switch:Yes.
