Startech 2x2 HDMI Matrix Auto Switcher cable

Save Time And Hassle By Automatically Switching Between Your Hdmi Audio/Video Sources, Using The Vs222hdq 2x2 Hdmi Matrix Switcher.

This Easy-To-Use Hdmi Matrix Switch Ensures Seamless Transition While Switching Video And Display Sources, With Edid Copy Maintaining Your Video Resolution.

Seamless Signal Selection:

- Ensure Seamless Transition While Switching Video Sources, With Edid Copy Maintaining Native Resolution With Support For 1080p.

Video Connection Emulation Ensures The Settings On Any Connected Computers Are Not Disrupted While Switching To A Different Video Source.

Effortless Control:

- Save Time By Connecting Two Hdmi Video Source Devices To Two Independent Hdmi Displays Instead Of Manually Connecting Individual Cables.

Mounting Hardware Is Also Included For A Tidy, Professional Installation.

Versatile Switching Options.

- Enjoy Hassle-Free Operation With Four Different Switching Modes:

- Automatic Port Selection:

Enables Your Most Recently Activated Video Source To Be Displayed Automatically.

- Priority Port Selection:

Prioritizes Input Number Two Above Input Number One.

If The Video Source Connected To Input Number Two Is Activated That Source Will Be Displayed.

- Matrix Port Selection:

Independently Switch Two Displays Between Two Video Sources.

- Manual Port Selection:

Enables You To Manually Select Your Hdmi Source With Easy-To-Use Front Panel Buttons.

Applications:

- Switch Between Different Video Sources On Your Digital Signage Display In Hospitals, Shopping Centers, Or Schools.

- Connect And Switch Between Two Video Sources And Two Displays On A Test Bench, For Troubleshooting Computers.

- Automatically Switch Between Your Blu-Ray Player, Set Top Box, Or Gaming Console In A Home Theatre Environment Advantage:

- Save Your Time, By Conveniently Accessing Multiple Hdmi Source Devices With 2 Independent Hdmi Displays.

- Hassle-Free Operation, With Four Video Selection Modes Including Automatic, Priority, Matrix And Manual.

- Worry-Free Switching, With Edid Copy Video And Connection Emulation Ensuring No Signal Loss.

Features:

- Auto Switching.

- Priority Switching.

- Built-In Manual Control Console.

- 2x2 Matrix Switching.

- Edid Emulation.

- Video Connection Emulation.

- Support For Video Resolution Up To 1080p.

- Mounting Hardware Included.

Specifications:

Connector(S):

Connector A:

- Hdmi (19 Pin) Connector B:

- Hdmi (19 Pin) Environmental:

- Operating Temperature:

0°C To 40°C (32°F To 104°F).

- Storage Temperature:

-20°C To 60°C (-4°F To 140°F).

- Humidity:

0%~80% Hardware:

- Av Input:

Hdmi.

- Av Output:

Hdmi.

- Ports:

2.

- Cabling:

Hdmi.

- Audio:

Yes.

- Rack-Mountable:

Yes Indicators:

Led Indicators:

- Display 1.

- Source 1 Activated.

- Display 2.

- Source 1 Activated Packaging Information:

- Package Height:

2.8 In [72 Mm].

- Package Length:

11.5 In [2.9 Cm].

- Package Width:

7.7 In [2.0 Cm].

- Package Weight:

19.2 Oz [545 G].

Performance:

- Max Distance:

10 M / 33 Ft.

- Maximum Digital Resolutions:

1920x1200 / 1080p Supported Resolutions:

- 1920x1200.

- 1920x1080 (1080p).

- 1280x720 (720p).

- Wide Screen Supported:

Yes.

- Audio.

Specifications:

7.1 Surround Sound Material:

Aluminum And Plastic:

- Product Length:

6.2 In [1.6 Cm].

- Product Width:

2.6 In [65 Mm].

- Product Height:

0.8 In [20 Mm].

- Weight Of Product:

10.2 Oz [290 G] Power:

- Power Source:

Ac Adapter Included.

- Input Voltage:

100.

- 240 Ac.

- Input Current:

0.6 A.

- Output Voltage:

12v Dc.

- Output Current:

1.5 A.

- Plug Type:

M.

- Power Consumption (In Watts):

18 In The Box:

- Hdmi Matrix Switch.

- Remote Control.

- Universal Power Adapter (Na, Eu, Uk, Au).

- Foot Pad Set.

- Mounting Kit.

- Instruction Manual.
