Startech 5G2A1SGBB hub

Features:

- 2-Port Usb-C Hub:

Includes a 1.8m USB-C host cable and a USB-C to USB-A dongle.

- 2-Port USB Type-A Hub (5Gbps).

- Overcurrent Protection.

- - RS-232 Serial Adapter (FTDI).

- Gigabit Ethernet.

- 100W PD Pass-Through.

- RS-232 Serial:

FTDI and COM hold.

- USB Enumeration/Transmit/Receive LEDs display real-time activity.

- 115.2 Kbps.

- 256-byte FIFO.

- Odd/Even/Marked/Space/None parity modes.

- 7 or 8 data bits.

- 1 or 2 stop bits.

- Gigabit Ethernet:

Integrated GbE converter to provide wired Ethernet to a laptop or desktop computer.

- GbE controller is fully IEEE 802.3u/ab compliant and supports WoL, Jumbo Frames and V-LAN Tagging.

- 10/100/1000 Mbps.

- Reliable.

Performance:

Connect an external USB-C power adapter (not included) to get 100W Power Delivery 3.0 pass-through power.

- 15W is reserved for the adapter to prevent device dropouts or overcharging.

- Up to 85W for charging.

- Our Advantage:

Connectivity tools included for IT professionals.

- USB event monitoring records the time of USB port usage.

- MAC address cloning.

- WIFI auto-switching utilities.

Specifications:

Ports and Interfaces:

- Connectivity.

Technology:

Wired.

- Host interface:

USB 3.2 Gen 1 (3.1 Gen 1) Type-C.

- Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports:

2.

- Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports:

1.

- USB power supply:

Yes.

- USB Power Delivery up to:

100 W.

- Serial port:

1 Connection:

- Ethernet:

Yes.

- Ethernet LAN (RJ-45) ports quantity:

1.

- Ethernet LAN, data transfer rate:

10,100,1000,2000 Mbit/s.

- Networking:

Yes.

- Network standards:

IEEE 802.1Q, IEEE 802.1p, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x.

- Jumbo Frames, stand:

Yes.

- Jumbo Plots:

9000.

- Flow control support:

Yes.

- Auto MDI / MDI-X:

Yes.

- Full duplex:

Yes.

- VLAN Tagging:

Yes.

Performance:

- Data transfer speed:

5 Gbit/s.

- LED indicators:

Yes.

- UASP support:

Yes Energy control:

- Power consumption (max):

15 W Software:

- Supported Windows operating system:

Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64, Windows 2000, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64.

- Supported MAC OS:

Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma.

- Supported Linux operating system:

Yes.

- Supported Server Operating System:

Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022.

- Other supported operating systems:

Windows XP Embedded Environmental conditions:

- Operating temperature range:

0.

- 50 °C.

- Storage temperature range:

-20.

- 70 °C.

- Relative humidity range for operation:

0.

- 95% Sustainability:

- Sustainability compliance:

Yes.

- Sustainability certificates:

CE, RoHS Weight and measurements:

- Broad:

128 mm.

- Depth:

55 mm.

- Height:

19 mm.

- Weight:

105 g.
