Startech HDMI 2.0 Switch 4 Port 4K cable

This 4-port HDMI video switch lets you share an HDMI 2.0 display or projector with four HDMI 2.0 video sources. The switch features four independent video inputs that can each support 4K resolution at 60Hz, making it the perfect solution for connecting four video sources to a display that has a limited number of HDMI 2.0 ports.

Astonishing picture quality with support for Ultra HD 4K at 60Hz
The HDCP 2.2 HDMI switch lets you harness the High Dynamic Range (HDR) capability of your HDMI 2.0 video sources and deliver it to your UHD 4K60 display. Unlike many 4K switches that only support a 30Hz refresh rate, this switch works with HDMI 2.0 displays with output resolutions of up to 3840 x 2160p at 60Hz.

Don´t be fooled by a clever spin on old technology. Many HDMI switches support 4K but will only work at a 30Hz refresh rate, or claim support for 60Hz but heavily compress their signal to a lower 4:2:0 chroma subsampling in order to work at inferior bitrates. This 4K 60Hz HDMI switch uses the latest components to offer full support for your HDMI 2.0 equipment, supporting true 4K resolution at 60Hz with 4:4:4 chroma subsampling. Support for HDMI 2.0 devices means this switch can transmit bandwidth up to 18Gbps, making it ideal for high-resolution computer tasks.

The switch is backward compatible with 4K 30Hz and 1080p displays, which ensures that it will work with lower resolution displays such as TVs or projectors around your site or in a digital signage application.
Hassle-free Operation with automatic switching

This switch ensures effortless operation with automatic switching that detects and selects a newly connected device. It´s perfect for automatically switching to a 4K media player such as a 4K UHD Blu-ray™ player as soon as it´s switched on. In your classroom or office boardroom, the automatic switch makes it easy to share your projector between multiple sources, which encourages on-the-fly collaboration among colleagues.


Specifications:

Connector(s):
- 4 - Connector A: HDMI (19 pin)
- 1 - Connector B: HDMI (19 pin)

Environmental:
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Storage Temperature: -10°C to 80°C (14°F to 176°F)
- Humidity: 10% to 85% RH

Hardware:
- Ports: 4
- AV Input: HDMI
- AV Output: HDMI
- Audio: Yes
- Industry Standards: HDMI 2.0
- Indicators:
- 4 - LED Indicators: input LEDs
- 1 - LED Indicators: power LED

Packaging Information:
- Package Height: 2.1 in [53.0 mm]
- Package Length: 5.9 in [15.1 cm]
- Shipping (Package) Weight: 15.3 oz [434.0 g]
- Package Width: 0.9 in [22.0 mm]

Performance:
- Maximum Digital Resolutions: 4K @ 60 Hz
- Supported Resolutions: 3840x2160 (4K) 60Hz 2560x1600 60Hz 1920x1200 60Hz 1920x1080 (1080p) 60Hz 1280x720 (720p) 60Hz
- Wide Screen Supported: Yes
- Audio Specifications: 7.1 Surround sound
- General Specifications: Lower resolutions are also supported

Physical Characteristics:
- Weight of Product: 5.4 oz [152.0 g]
- Color: Black
- Material: Steel
- Product Length: 4.8 in [12.3 cm]
- Product Width: 2.0 in [51.0 mm]
- Product Height: 0.8 in [20.0 mm]

Power:
- Power Source: AC Adapter Included
- Input Voltage: 100 - 240 AC
- Input Current: 0.4 A
- Output Voltage: 5 DC
- Output Current: 2000 mA
- Plug Type: M

What´s in the Box:
- 1 - Included in Package: HDMI video switch IR remote control (with CR2025 battery)Universal Power Adapter (NA, EU, UK, ANZ)
