Startech RS232 DB9 CAT.5 Ethernet Extensor Extender

Extend an RS232 serial connection up to 1000 meters (3300 feet) using Cat 5 cabling.

The RS232EXTC1EU Serial over Cat 5 Extender allows you to increase the distance of your RS232 Serial connection by up to 1000 meters (3300 feet), giving you the ability to connect serial peripheral devices up to a kilometer away from your system.

- an incredible 65x greater than normal RS232 serial cable length restrictions would permit.

The Serial Extender is a cost-effective serial extension solution and entirely hardware-based, eliminating the need to install additional software, allowing for a completely plug and play installation.

The hardware can be setup in minutes, using existing or new Cat 5 or better Ethernet cabling.

Perfect for use in industrial monitoring and control, POS, security, medical, and traffic flow applications, the RS232 Serial over Cat 5 extender maintains the RS232 standard with support for data transfer rates of up to 230 Kbps.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage:

- Provides you with flexibility when choosing the location of your serial peripherals by dramatically increasing the maximum RS232 serial cable length.

- Pure hardware design, no software or drivers required ensuring a simple plug and play installation.

- Enables use of separate control rooms away from harsh environmental conditions where serial devices may be located.

Specifications:

Ports & interfaces:

- Host interface:

VGA.

- Output interface:

Serial.

- Serial ports quantity:

1.

- Serial interface type:

RS-232 Design:

- Internal:

No Power:

- Power supply type:

DC Operational conditions:

- Operating temperature (T-T):

0.

- 70 °C.

- Storage temperature (T-T):

0.

- 85 °C.

- Operating relative humidity (H-H):

0.

- 90% Weight & dimensions:

- Width:

65 mm.

- Depth:

92 mm.

- Height:

22 mm.

- Weight:

1 kg Packaging data:

- Package width:

57 mm.

- Package depth:

315 mm.

- Package height:

138 mm Other.

Features:

- Data transfer rate:

0.115 Mbit/s.

- Connectivity.

Technology:

Wired.

- Power requirements:

115V.

- Ethernet LAN (RJ-45) ports:

1.
