Raymarine CAM210 IP camera

Ruggedised, High Definition, Day and Night network bullet video camera suitable for all above deck applications. Integrated sun-cover for maximum visibility and small frame size for easy installation anywhere on the boat.


Features:

- Plug and play integration with Raymarine MFD’s running Lighthouse II
- Power over Ethernet (PoE) or direct 12v DC power supply
- High bright IR LEDs for operation in total darkness
- Digital Defog processing improves the captured image in poor weather conditions (such as smog, fog or smoke)
- Intelligent IR technology for clear video images at night in all conditions


Specifications:

- CPU: 32-bit ARM9 RISC CPU up to 432MHz
- Flash / SDRAM: 128MB / 128MB

Camera:
- Image Sensor: 2.0 Megapixel 1/2.8´ SONY progressive scan CMOS(Exmor)
- Total Pixels: 1952(H) x 1116(V) 2.18 Megapixel
- Effective Pixels: 1944(H) x 1104(V) 2.15 Megapixel
- S/N Ratio: More than 50dB
- Minimum Illumination: 0Lux (IR On)
- IR Distance: 20m
- Day & Night: ICR
- Lens: 6.0mm Megapixel Board Lens
- Field of View: Diagonal = 63.6 deg +/- 3 deg
- Horizontal = 53.3 deg +/- 3 deg
- Vertical = 33.1 deg +/- 3 deg

Video:
- Video Compression: H.264 High Profile@4.0, MJPEG –Image quality: 3 Steps
- Resolution: Up to 1920 x 1080 (Full HD)
- Frame Rate: H.264 Up to 30fps with 1920x1080 | MJPEG Up to 30fps with VGA resolution Video Streaming: Support multi stream with H.264, MJPEG Adjustable frame rate
- CVBR/CBR in H.264
- Pan / Tilt / Zoom: Digital Pan, Tilt and Zoom
- Image Setting: Day & Night Auto White Balance Auto Exposure Privacy Mask Effects - Colour, Sharpness, Mirror / V-Flip

System Integration:
- Security: Password protection, User access log, HTTPS encryption
- Supported Protocol: HTTP, HTTPS, FTP, SMTP, UPnP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP
- Intelligent Video: Motion detection up to 1920x1080 with 4x3 blocks

Physical:
- Power Source: DC12V/1.5A, PoE(Power over Ethernet): 802.3af
- Power Consumption: Max. 3.3W, Max. 5.3W with IR
- Net Weight: 900g
- LEDs: Power, Network Connection
- Dimensions: 83.8mm(W) x 155mm(H) x 178.1mm(D) including Bracket
- General Operation Temperature: 0 degree~40 degree Celsius(32F~104F)
- Storage Temperature: -10 degree~50 degree Celsius(14F~122F)
