Ancor Adhesive Lined Heat

ANCOR Adhesive Lined Heat Shrink Tubing | Ultimate Waterproof Protection for Electrical Cables

Ensure the absolute longevity and reliability of your electrical connections with ANCOR´s Adhesive Lined Heat Shrink Tubing, the premier choice for professionals and enthusiasts in the Electronics and Accessories field. Designed to withstand the most demanding marine and automotive environments, this tubing provides a permanent, robust, and environmentally sealed solution for insulating and protecting your critical wiring and Cables. When failure is not an option, trust ANCOR to deliver uncompromising performance.

Unrivaled Environmental Protection and Durability

Experience peace of mind with a seal that is truly impervious. The tubing features a specially formulated heat-activated adhesive lining that melts and flows during the shrinking process. This creates a completely waterproof, airtight, and corrosion-proof barrier, effectively locking out damaging elements like salt water, oil, battery acids, and moisture. This superior seal also offers excellent protection against sunlight and UV degradation, making it ideal for exposed applications. Engineered from advanced cross-linked polyolefin, this tubing is significantly stronger and more abrasion-resistant than standard PVC tubing and possesses superior flame-retardant properties, as it will not burn like PVC, adding a critical layer of safety to your projects.

Superior Performance and Versatility

Achieve a perfect, professional fit every time. ANCOR´s heat shrink boasts the highest shrink ratio in the industry, shrinking down to one-third of its original size (3:1). This exceptional versatility means a single piece can conform tightly over a wide range of wire sizes and irregular shapes, reducing the need for multiple SKUs and ensuring a snug, secure fit. The tubing also provides essential strain relief, supporting the wire at the connection point to prevent fatigue and breakage from vibration and movement. Certified to UL 224 standards and capable of operating in extreme temperatures, this is the definitive solution for protecting splices, terminals, and connections on any vessel, vehicle, or outdoor installation.

This package contains one 48-inch (122 cm) long section of Red tubing with a 1/2-inch (12.7 mm) diameter that shrinks to 5/32 inches (4 mm).

Specifications:

* Material: Cross Linked Polyolefin Tubing
* Shrink Ratio: 3:1 (Highest in the industry)
* Shrink Temperature: 257° F / 125° C
* Operating Temperature Range: -40° C to 110° C
* Certifications: UL 224
* Length (Imperial): 48 in
* Length (Metric): 122 cm
* Initial Diameter (Imperial): 1/2 in
* Initial Diameter (Metric): 12.7 mm
* Shrinks To (Imperial): 5/32 in
* Shrinks To (Metric): 4 mm
* Wire Range (Imperial): 8 - 4 AWG
* Wire Range (Metric): 8 - 19 mm²
* Each in Package Height (in): 0.500
* Each in Package Width (in): 0.500
* Each in Package Length/Depth (in): 20.000
* Each in Package Weight (oz): 1.450
