Garmin Plotter con transductor y cartografía Echomap Ultra 2 10´´

With big, crisp, sunlight-readable touchscreen displays, these versatile chart plotters put a world of fish finding capability at your fingertips. They support Garmin Navionics+™ and Garmin Navionics Vision+™ mapping and the transducer bundle adds Ultra High-Definition scanning sonars as well as CHIRP traditional sonar.

What You´Ll Love:

Live scope™ Sonar Support:
- The ECHOMAP Ultra 2 series supports the full lineup of Live Scope live-scanning sonar products.

Built-In Uhd Sonar:
- Select models are bundled with a GT56 transducer which provides Garmin CHIRP traditional sonar and Ultra High-Definition Clearvu™ and SideVü™ scanning sonars for photo-like images of what’s beneath the surface.

Vivid Colour Palettes:
- High-contrast vivid scanning sonar colour palettes make it easier than ever to distinguish targets and structure.

Charts & Maps:
- Bring a fresh new look and feel to your chart plotter with optional Garmin Navionics+™ or premium Garmin Navionics Vision+™ cartography featuring integrated coastal/inland content, access to daily updates, Auto Guidance+™ technology and more.

Wireless Networking:
- If you have another compatible ECHOMAP Ultra 2 or ECHOMAP UHD2 chart plotter on your boat, you can wirelessly share information such as sonar3, waypoints and routes with them.

Stay Connected:

Multi-Band Gps:
- Get improved position accuracy with multi-band GPS

Nmea 2000® Network Compatibility:
- Connect to heading sensors, autopilots, Fusion-Link audio system

Active captain® App:
- Pair with the free smart-device app for software updates, screen recording, Garmin Quickdraw™ Community data and more.

Force® Trolling Motor:
- Wirelessly connect to your Force trolling motor to navigate to waypoints, draw and follow routes, and more.

Take It With You:
- The quick-disconnect bail mount lets you quickly install and remove your unit.


Features:

- 10″ Or 12″ Touchscreens
- Supports Live scope™ Sonar1 And More
- Supports Garmin Navionics+™ And Garmin Navionics Vision+™ Mapping
- Wirelessly Share Sonar, Waypoints And Routes2
- Capture Screen Recordings To Share Fish Catches
- Multi-Band Gps For Improved Position Accuracy


Specifications:

General:
- Dimension: 29.5 x 19.5 x 9.8 cm (11.6″ x 7.7″ x 3.9″)
- Weight: 1.8 kg (4 lbs)
- Waterproof: IPX7
- Touchscreen: Yes
- Display Type: WXGA, IPS
- Display Size: 21.7 x 13.6 cm; 21.7 cm diagonal (8.5″ x 5.4″; 10″ diagonal)
- Display Resolution: 1280 x 800 pixels
- Mounting Options: Bail or flush
- Input: Touchscreen with Keyed Assist

Maps & memory:
- Accepts Data Cards: 2 microSD Cards
- Waypoints: 5000
- Track points: 50,000
- Tracks: 50 saved tracks
- Navigation Routes: 100

Sensors:
- GPS: Yes
- GLONASS: Yes
- Galileo: Yes
- BeiDou: Yes
- Has built-in receiver: Yes
- Receiver: 10 Hz
- NMEA 2000® compatible: Yes
- Supports WAAS: Yes
- Supports multi-band, multi-constellation GPS: Yes

Built-in maps:
- Built-in Auto Guidance+: Yes
- Garmin Navionics+ Inland & Coastal: Yes (see Additional)
- Tide tables: Yes (see Additional)

Optional map support:
- BlueChart g3: Yes
- BlueChart g3 Vision: Yes
- Garmin Navionics+™: Yes
- Garmin Navionics Vision+™: Yes
- TOPO 100K: Yes
- Standard Mapping: Yes
- Garmin Quickdraw Contours: Yes

Chartplotter features:
- AIS: Yes
- DSC: Yes
- Supports Fusion-Link™ compatible radios: Yes
- Active Captain Mobile Planning Compatible: Yes
- Sailing features: Yes

Electrical features:
- Power Input: 9 to 18 Vdc
- Typical current draw at 12 Vdc: 2.3 A
- Maximum current draw at 12 Vdc: 5 A
- Maximum power usage at 10 Vdc: 34 W

Sonar features & specifications:
- Displays sonar: Yes
- Power output: 600 W
- Traditional sonar (dual frequency/beam): built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)
- ClearVü: Built-in 260/455/800/1000/1200 kHz
- SideVü: Built-in 260/455/800/1000/1200 kHz
- Panoptix™ sonar: Yes
- LiveScope: Yes

Connections:
- NMEA 2000® ports: 1
- Garmin Marine Network Ports: 2 (large connector)
- 12-pin transducer ports: 12-pin scanning sonar
- ANT+ (Connectivity): Yes
- Garmin Wi-Fi network (local connection): Yes

Compatible:
- AIS™ 800 Blackbox Transceiver
- Reactor™ 40 Steer-by-wire Standard Corepack
- Reactor™ 40 Steer-by-wire Corepack for Volvo-Penta®
- Reactor™ 40 Mechanical/Retrofit/Solenoid Corepack
- Reactor™ 40 Hydraulic Autopilot
- 2-Liter Pump Kit
- Force® Kraken Trolling motor
- GCV™ 20 Sonar Black Box
- GMI™ 20
- LiveScope™ Plus System, With GLS 10™ and LVS34 Transducer
- Panoptix LiveScope™ System
- Panoptix™ PS30
- Panoptix™ PS51-TH
- quatix® 7X – Solar Edition
- Reactor™ 40 Hydraulic Autopilot
- Reactor™ 40 Hydraulic Corepack with SmartPump v2
- Reactor™ 40 Steer-by-wire Corepack for Volvo-Penta®
- Reactor™ 40 Steer-by-wire Corepack for Yamaha® Helm Master™
- Reactor™ 40 Mechanical/Retrofit/Solenoid Corepack

In The Box:
With transducer:
- ECHOMAP Ultra 102sv
- GT56UHD-TM transducer
- Charging/data cable
- Bail Mount With Quick Release Cradle
- Protective sun cover
- Hardware
- Documentation

Without Transducer:
- ECHOMAP Ultra 102sv
- Charging/data cable
- Bail Mount With Quick Release Cradle
- Protective sun cover
- Hardware
- Documentation
