Kicker KXM 5 channels class D amplifier

KICKER KXM 5-Channel Class D Marine Amplifier: The Ultimate All-In-One Audio Solution

Elevate your audio experience on the water or the trail with the KICKER KXM 5-Channel Class D Marine Amplifier. Engineered to be the one-and-done command center for your entire sound system, this powerhouse is one of the most versatile marine Amplifiers on the market. It delivers immense, crystal-clear power to four full-range speakers and a dedicated subwoofer from a single, compact, and incredibly efficient chassis. Say goodbye to the complexity of multiple amps and wiring, and hello to a streamlined installation that provides breathtaking, full-range sound for any boat, UTV, or outdoor vehicle.

Built to Conquer the Elements
KICKER´s KXM series amplifiers are designed from the ground up to withstand the harshest marine and powersports environments. The internal circuit board features a moisture-deterring conformal coating, protecting the sensitive electronics from salt, fog, and humidity. All power, speaker, and RCA connections are gasket-sealed to lock out moisture, while the robust chassis is UV-treated to resist sun damage. Every piece of hardware is forged from rustproof 316L stainless steel, ensuring this amplifier not only performs flawlessly but also maintains its integrity and appearance season after season. This weather-resistant design is fully compliant with ABYC and NMMA standards for ultimate reliability and peace of mind.

Unleashed Power and Precision Control
At its core, the KXM 5-channel amplifier is a sonic beast. Its high-efficiency Class D design means it draws less current from your vehicle’s charging system, runs cooler, and requires less space than traditional amplifiers, all while producing massive power. You gain complete control over your sound with a studio-grade 24dB crossover and a 24dB subsonic filter on the subwoofer channel, allowing you to precisely tune frequencies for optimal speaker and subwoofer performance. For those who crave deep, impactful bass, the KickEQ+™ feature provides up to 18dB of variable bass boost, letting you dial in the perfect low-end punch.

Main Features:
* Single Amplifier Solution: Powers four speakers and a subwoofer, simplifying system design and installation.
* Marine-Grade Construction: Features conformal-coated circuit boards, gasket-sealed connections, and stainless-steel hardware for superior weather resistance.
* Class D Power Plant: Delivers exceptional power with high efficiency, a small footprint, and minimal heat generation.
* FIT2™ (Fail-Safe Integration Technology): Ensures seamless integration with nearly any factory or aftermarket radio, eliminating noise and interference.
* Precision Audio Tuning: Includes a 24dB crossover and subsonic filter for detailed sound shaping.
* KickEQ+™ Bass Boost: Offers up to 18dB of variable boost at 40Hz for powerful, customized bass response.
* Easy Gain Matching: A gain control with an "Optimal Input" indicator light makes setup simple and precise, preventing distortion.
* Remote Bass Ready: Compatible with the KMLC wireless remote (sold separately) for convenient, on-the-fly subwoofer level control from the helm or driver´s seat.

---

Technical Specifications

Amplifiers

* Model: KXM800.5
* RMS Power Output @ 14.4V, 4Ω Stereo, ≤ 1% THD+N: 50W x 4 (Amp 1)
* RMS Power Output @ 14.4V, 2Ω Stereo, ≤ 1% THD+N: 100W x 4 (Amp 1)
* RMS Power Output @ 14.4V, 4Ω Mono, ≤ 1% THD+N: 200W x 1 (Subwoofer Amp)
* RMS Power Output @ 14.4V, 2Ω Mono, ≤ 1% THD+N: 400W x 1 (Subwoofer Amp)
* Frequency Response (Amp 1): 10Hz–20kHz
* Frequency Response (Subwoofer Amp): 10Hz-160Hz
* Signal-to-Noise Ratio: >95dB, A-weighted, re: rated power
* Crossover (Amp 1): High Pass 10-500Hz, 24dB/octave
* Crossover (Subwoofer Amp): Low Pass 40-160Hz, 24dB/octave
* Subsonic Filter: 10-80Hz, 24dB/octave
* KickEQ+™ Bass Boost: Variable 0–18dB @ 40Hz
* Dimensions (L x H x W): 14-3/16" x 2-1/8" x 8-5/16" (36.0x5.5x21.1 cm)
