Nauticled PWM-10A-Multi CV Button

NAUTICLED PWM-10A-Multi CV Button

Product Description

Elevate your lighting control to a new level of sophistication and simplicity with the NAUTICLED PWM-10A-Multi CV Button. This advanced electronic accessory is a masterclass in minimalist design and powerful functionality, engineered to provide comprehensive control over your 12V or 24V DC Constant Voltage LED systems from a single, elegant push-button. Designed for the demanding conditions of marine, automotive, and high-end architectural applications, this controller consolidates the functions of multiple switches and dimmers into one intuitive interface, decluttering your dashboard or control panel while expanding your creative lighting possibilities.

Experience unparalleled versatility. The "Multi" in its name signifies its core strength: the ability to intelligently manage a wide array of LED lighting types. Whether you are installing simple single-color accent lights, dynamic Tunable White (CCT) strips for mood setting, vibrant RGB color-changing arrays, or sophisticated RGBW systems for a full spectrum of colors and pure white, this single controller handles it all. It eliminates the need for separate, dedicated controllers for each type of lighting, making it the ultimate all-in-one solution for complex lighting projects.

The NAUTICLED PWM-10A-Multi is built upon a foundation of smooth, flicker-free performance. By utilizing high-frequency Pulse Width Modulation (PWM), it delivers seamless dimming from 100% brightness down to a subtle glow without the annoying flicker or stepping common in lesser-quality dimmers. This ensures a comfortable and visually pleasing experience, crucial for interior cabins, cockpits, and living spaces. Furthermore, its integrated memory function conveniently recalls the last used setting, so your lights return to your preferred color and brightness level every time you power them on.

Key Benefits

* All-in-One Lighting Control: Streamline your installation by using a single device to control Single Color, Tunable White (CCT), RGB, and RGBW Constant Voltage LED lighting.
* Intuitive Single-Button Interface: Declutter your control panel with a minimalist yet powerful push-button that manages all functions, from on/off to dimming and mode selection.
* Flawless Dimming Performance: Enjoy smooth, continuous, and flicker-free brightness adjustments thanks to advanced PWM technology, perfect for creating the ideal ambiance.
* Robust and Reliable: Engineered by NAUTICLED for durability, it operates on a wide 12-24V DC voltage range, making it perfectly suited for the rigorous demands of marine, RV, and off-grid environments.
* Smart Memory Function: The controller automatically saves your last brightness and color setting, restoring it instantly upon the next power-up for maximum convenience.

Main Features

* Multi-function output supports four distinct modes of LED control.
* High-frequency Pulse Width Modulation (PWM) output for superior dimming quality.
* Integrated, tactile push-button for all operational controls.
* Last-setting memory retention after power loss.
* Wide operating voltage input for flexible system compatibility.
* High 10A current capacity to power substantial lengths of LED strips.
* Designed for use with Constant Voltage (CV) LED products.
* Compact form factor for easy and discreet panel-mount installation.

Buttons

The intelligence of the NAUTICLED PWM-10A-Multi is centered on its single-button control system. This interface is designed to be intuitive, providing access to a deep feature set through simple, distinct actions:

* Short Press: Toggles the connected LED lights ON and OFF.
* Long Press (Hold): Smoothly ramps the brightness up or down. Release the button at the desired intensity. Press and hold again to dim in the opposite direction.
* Double Press (Quickly): Cycles through the various operational modes or color scenes specific to the connected LED type .

Technical Specifications

* Model: NAUTICLED PWM-10A-Multi CV Button
* Input Voltage: 12V - 24V DC
* Output Signal: Constant Voltage (CV) / PWM
* Maximum Load Current: 10A Total
* Control Interface: Integrated Push Button
* Supported LED Types: Single Color, Tunable White (CCT), RGB, RGBW
* Protection: Reverse Polarity Protection
* Connections: Wire Leads
* Mounting: Panel Mount
* Operating Temperature: -20°C to +60°C
