Intel Processore Pentium G4560 3.5GHz

Intel Pentium G4560. Processor family: Intel Pentium G, Processor frequency: 3.5 GHz, Processor socket: LGA 1151 (Socket H4). Memory channels: Dual-channel, Maximum internal memory supported by processor: 64 GB, Memory types supported by processor: DDR3L-SDRAM,DDR4-SDRAM. On-board graphics adapter model: Intel® HD Graphics 610, Maximum on-board graphics adapter memory: 64 GB, On-board graphics adapter outputs supported: DisplayPort,Embedded DisplayPort (eDP),HDMI. Thermal Design Power (TDP): 54 W. PCI Express configurations: 1x16,1x8+2x4,2x8, Supported instruction sets: SSE4.1,SSE4.2, Scalability: 1S


Features:

Exceptional Performance for Work, Play, and Beyond:
- Prime yourself for more of everything you want and need. The latest Intel® Pentium® processors let you stream, share, shop, play, create, and consume—all at the same time.
- Discover a new dimension in productivity with Intel’s next-generation Pentium® processors. Performance optimized to accelerate portable 2 in 1s, laptops, towers, desktops, and All-in-Ones. Go thinner, sleeker, and smaller with reliability you can count on.

Featuring Splendid Audiovisuals:
- Whether you are streaming Ultra HD video to a big screen or simply reading the news, get impressive multimedia and entertainment features in a wide range of devices with the latest Intel® Pentium® processors.

Chat, Shop, or Surf in Style:
- Get exceptional computing performance to keep your life moving. Browse the web, shop, and communicate with friends simultaneously. With improved graphics, light weight and low-power consumption, witness a processor built for better experiences.

Whatever You Do, Do It Faster:
- The new Intel® Pentium® processor has improved functionality for multitasking, helping you get more work done with less stress. Create, edit, and organize critical documents while managing photos and staying on top of emails.

Never Stop Playing:
- The Intel® Pentium® features upgraded graphics and computing performance to juice up your casual gaming life. Level up your enjoyment with more seamless action and snappier gameplay experiences.


Specifications:

Processor:
- Processor family: Intel Pentium G
- Processor frequency: 3.5 GHz
- Processor cores: 2
- Processor socket: LGA 1151 (Socket H4)
- Component for: PC
- Processor lithography: 14 nm
- Box: Yes
- Cooler included: Yes
- Processor manufacturer: Intel
- Processor model: G4560
- Processor threads: 4
- System bus rate: 8 GT/s
- Processor operating modes: 32-bit,64-bit
- Processor series: Intel Pentium G4500 Series For Desktop
- Processor cache: 3 MB
- Stepping: B0
- Bus type: DMI3
- Processor codename: Kaby Lake
- Processor code: SR32Y
- Processor ARK ID: 97143

Memory:
- Memory channels: Dual-channel
- Maximum internal memory supported by processor: 64 GB
- Memory types supported by processor: DDR3L-SDRAM,DDR4-SDRAM
- Memory clock speeds supported by processor: 1333,1600,2133,2400 MHz
- Memory voltage supported by processor: 1.35 V
- ECC: Yes

Graphics:
- On-board graphics adapter: Yes
- On-board graphics adapter model: Intel® HD Graphics 610
- Maximum on-board graphics adapter memory: 64 GB
- On-board graphics adapter outputs supported: DisplayPort,Embedded DisplayPort (eDP),HDMI
- On-board graphics adapter base frequency: 350 MHz
- On-board graphics adapter dynamic frequency (max): 1050 MHz
- Number of displays supported (on-board graphics): 3
- On-board graphics adapter 4K support: Yes
- On-board graphics adapter DirectX version: 12.0
- On-board graphics adapter OpenGL version: 4.4
- On-board graphics adapter maximum resolution (DisplayPort): 4096 x 2304 pixels
- On-board graphics adapter maximum resolution (eDP - Integrated Flat Panel): 4096 x 2304 pixels
- On-board graphics adapter maximum resolution (HDMI): 4096 x 2304 pixels
- On-board graphics adapter refresh rate at maximum resolution (DisplayPort): 60 Hz
- On-board graphics adapter refresh rate at maximum resolution (eDP - Integrated Flat Panel): 60 Hz
- On-board graphics adapter refresh rate at maximum resolution (HDMI): 24 Hz
- On-board graphics adapter ID: 0x5902

Power:
- Thermal Design Power (TDP): 54 W
- Execute Disable Bit: Yes
- Idle States: Yes
- Thermal Monitoring Technologies: Yes
- Maximum number of PCI Express lanes: 16
- PCI Express slots version: 3.0
- PCI Express configurations: 1x16,1x8+2x4,2x8
- Supported instruction sets: SSE4.1,SSE4.2
- Scalability: 1S
- CPU configuration (max): 1
- Embedded options available: No
- Graphics & IMC lithography: 14 nm
- Thermal solution specification: PCG 2015C
- PCI Express CEM revision: 3.0
- Market segment: DT
- Harmonized System (HS) code: 8542310001

Processor special features:
- Intel® Hyper Threading Technology (Intel® HT Technology): Yes
- Intel® Identity Protection Technology (Intel® IPT): Yes
- Intel® Turbo Boost Technology: No
- Intel® Quick Sync Video Technology: Yes
- Intel® InTru™ 3D Technology: Yes
- Intel® Clear Video HD Technology (Intel® CVT HD): Yes
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Enhanced Intel SpeedStep Technology: Yes
- Intel Trusted Execution Technology: No
- Intel® Memory Protection Extensions (Intel® MPX): Yes
- Intel Enhanced Halt State: Yes
- Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID): Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel® Secure Key: Yes
- Intel TSX-NI: No
- Intel Stable Image Platform Program (SIPP): No
- Intel® OS Guard: Yes
- Intel Clear Video Technology: Yes
- Intel Software Guard Extensions (Intel SGX): Yes
- Intel 64: Yes
- Intel Identity Protection Technology version: 1.00
- Intel Secure Key Technology version: 1.00
- Intel Stable Image Platform Program (SIPP) version: 0.00
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel TSX-NI version: 0.00
- Conflict-Free processor: Yes
- Intel® Optane™ Memory Ready: No
- Intel® Boot Guard: Yes
- Intel® vPro™ Platform Eligibility: No

Operational conditions:
- Tjunction: 100 °C

Technical details:
- Processor cache: 3072 KB
- Product type: Processor
- Maximum graphics adapter memory: 64 GB
- Bus bandwidth: 8
- Bus type units: GT/s
- Launch date: Q1´17
- Maximum resolution & refresh rate (DisplayPort): 4096x2304@60Hz
- Maximum resolution & refresh rate (HDMI): 4096x2304@24Hz
- Maximum resolution & refresh rate (Integrated Flat Panel): 4096x2304@60Hz
- Status: Discontinued
- Maximum memory: 64 GB
- Processor brand name: Intel Pentium
- Last change: 63903513
- Product family: Intel Pentium Processor
- Bus speed: 8 GT/s
- Processor ID: 0x5902

Weight & dimensions:
- Processor package size: 37.5 x 37.5 mm

Other features:
- Maximum internal memory: 65536 MB
- Video decoding: Yes
