Blue Sea Systems AC Toggle Source Selector 230V/Panel 32A

BLUE SEA SYSTEMS AC Toggle Source Selector 230V/Panel 32A

Safely and reliably manage your vessel´s or vehicle´s AC electrical system with the Blue Sea Systems AC Toggle Source Selector Panel. This robust and intuitive panel is a critical component for any setup with two separate AC power sources, such as shore power and an onboard generator or inverter. Designed for the demanding European market, it provides a seamless and, most importantly, safe method to switch between power inputs, ensuring your appliances and electronics receive consistent and protected power.

This panel is engineered with user safety as its paramount concern. The primary benefit lies in its foolproof design that completely eliminates the dangerous possibility of connecting two AC sources simultaneously. This prevents hazardous back-feeding to shore power lines, protects your generator from damage, and safeguards personnel from electrical shock. The integrated lockout mechanism makes it physically impossible to have both main breakers in the "ON" position at the same time, offering peace of mind and simplifying power management.

AC Toggle Source Selector .

Double pole AC main circuit breakers with installed lockout slide.

The Blue Sea Systems panel is built to provide comprehensive circuit protection. The inclusion of double pole circuit breakers is a significant advantage, as they simultaneously disconnect both the hot and neutral wires. This is essential for enhanced safety in marine and mobile environments, providing complete isolation of the circuit during switching or in an overcurrent situation. The 32A rating of the breakers is ideal for managing common onboard loads, while the panel itself is constructed to handle a total amperage of up to 50A, providing capacity for future system expansion.

Key Benefits:

* Uncompromised Safety: The mechanical lockout slide is the core safety feature, as it prevents connecting both AC sources simultaneously. This protects your equipment, the power grid, and anyone on board from dangerous electrical faults.
* Superior Circuit Protection: Equipped with double pole circuit breakers, the panel offers superior protection by isolating both hot and neutral lines, a critical requirement for marine and specialty vehicle electrical systems.
* Clear & Immediate Status Indication: Bright red LED indicators illuminate to show when a source is "ON," while green LEDs indicate power is "Available" from a source, even when it is not selected. This provides at-a-glance confirmation of your electrical system´s status.
* Durable & Reliable Construction: Built by Blue Sea Systems, a leader in marine-grade electrical components, this panel is designed to withstand the harsh conditions of a marine or mobile environment, ensuring long-lasting performance.
* User-Friendly Operation: The simple toggle switch action, combined with clear, backlit labels, makes operating the panel effortless, even in low-light conditions.

Main Features:

* Switches two 230V AC sources
* Installed mechanical slide prevents simultaneous source connection
* Double pole C-Series circuit breakers installed
* Green "Power Available" LED indicators for each source
* Red "Reverse Polarity" warning LED indicator
* Red "ON" LED indicators for selected source
* Backlit labels for easy identification

Technical Specifications:

* Product Attribute: Panels
* Voltage: 230V AC
* Circuit Breaker Amperage: 32A
* Maximum Panel Amperage: 50 Amperes
* Poles: 2
* Sources: 2
* Panel Material: Heavy-duty 0.125" aluminum alloy
