E-T-A GS11433 Push Button Thermal Circuit Breaker | 20A

Ensure superior and reliable overcurrent protection for your critical electrical systems with the E-T-A GS11433 Push Button Thermal Circuit Breaker. As a world-leading solution in circuit protection, this high-performance component is engineered to safeguard your valuable equipment, prevent damage from overloads and short circuits, and minimize costly downtime. Ideal for a wide range of applications in the electronics and electrical connections sector, the GS11433 combines precision engineering with user-friendly functionality, making it the premier choice over traditional single-use fuses.

Unmatched Protection and Reliability

The core benefit of the E-T-A GS11433 lies in its advanced, reusable protection mechanism. Unlike a fuse that must be replaced after every overcurrent event, this thermal circuit breaker can be quickly and easily reset, saving you time, maintenance effort, and replacement costs. Its robust design is built for a long service life, providing consistent and dependable performance you can trust. The integrated safety features ensure that your circuits are protected without compromise, offering peace of mind in demanding industrial, commercial, and even medical environments.

Key Features

This device is a single pole thermal circuit breaker with a press-to-reset, tease-free, trip-free, snap action mechanism. Its convenient threadneck design is optimized for secure and straightforward panel mounting.
* Trip-Free Mechanism: A critical safety feature that ensures the circuit remains open during an overload condition, even if the reset button is manually held in the "on" position. This prevents the device from being defeated, guaranteeing uncompromised protection.
* Tease-Free, Snap Action Operation: The internal contacts open and close with a decisive snap action, regardless of how slowly the reset button is operated. This prevents arcing and contact welding, significantly enhancing the device´s reliability and lifespan.
* Press-to-Reset Functionality: Following a trip, the circuit can be restored with a simple push of the button. This intuitive operation allows for rapid system recovery, reducing operational interruptions.
* Clear Visual Trip Indication: When the breaker trips, the button extends and remains in the "off" position, providing an immediate and clear visual cue that an overcurrent event has occurred and requires attention.
* Panel Mount Design: The threaded neck and included hardware allow for fast, easy, and secure installation into control panels, equipment housings, and distribution boards, ensuring a clean and professional finish.
* Proven E-T-A Quality: Manufactured by E-T-A, a global leader in circuit protection, this breaker is backed by decades of engineering excellence and holds numerous international approvals (including UL, CSA, and VDE), certifying its safety and performance.

Buttons

The prominent push button actuator is central to the GS11433´s design. It serves as a multi-function interface, providing both the manual reset control and a clear visual status indicator. Its ergonomic design ensures reliable actuation, while its distinct positional change upon tripping makes fault diagnosis quick and effortless from the front of the panel.

Technical Specifications
* Product Type: Thermal Circuit Breaker
* Model Series: 1140-G
* Part Number: GS11433
* Electricity (Current Rating): 20 A
* Voltage Rating: AC 250 V; DC 50 V
* Number of Poles: 1 (Single Pole)
* Actuator Type: Push Button (Press-to-Reset)
* Mounting Style: Panel Mount, Threadneck (M12x1)
* Termination: Blade Terminals
* Typical Life: 5.000 cycles at rated current
* Approvals: UL 1077, CSA C22.2 No. 235, VDE (EN 60934), CCC
