Ropeye TDP 12 bushing

ROPEYE TDP 12 Bushing | High-Performance Through Deck Fitting

Revolutionize your deck layout with the ROPEYE TDP 12 Bushing, a state-of-the-art through-deck fitting engineered for the modern sailor who demands maximum performance, reliability, and a clean aesthetic. Designed as the ultimate solution for leading control lines, halyards, and sheets through the deck, this fitting eliminates friction, saves weight, and ensures a completely watertight seal, making it an essential upgrade for racing yachts and performance cruising vessels alike.

Unmatched Performance and Core Benefits

Experience the significant advantages of integrating the ROPEYE TDP 12 into your boat´s hardware. Its design philosophy centers on delivering exceptional strength from a minimal footprint. This results in an incredibly lightweight component that helps reduce weight aloft and overall displacement, contributing to better sailing performance. The smooth, curved geometry allows ropes to run with virtually zero friction, ensuring immediate and precise sail adjustments without unnecessary wear on your expensive high-tech lines. Furthermore, the innovative design guarantees a 100% watertight installation, protecting your deck core from water intrusion and giving you complete peace of mind in even the most challenging sea conditions.

Innovative Features for the Discerning Sailor

The ROPEYE TDP 12 is distinguished by its intelligent and robust features. At its core is the unique ´Stuck-in-Place´ (SiP) technology. This feature ensures that the bushing remains securely in the deck, even when no rope is running through it, preventing it from being lost or misplaced during rigging changes. The installation process is streamlined and can be completed by a single person from the top of the deck, saving valuable time and effort. Its low-profile on-deck flange creates a snag-free, clean deck layout, reducing trip hazards and allowing for more efficient crew work. Built for longevity, this fitting contains no moving parts, which means no maintenance, no corrosion, and no failures, just consistent, reliable performance year after year.

As one of the most advanced Bushings in the marine fitting market, the TDP 12 is purpose-built to guide lines at any angle through a surface with minimal resistance. It is the perfect interface between your high-load lines and your deck structure, preserving the integrity of both.

Technical Specifications:

* Model: ROPEYE TDP 12
* Attribute: Bushings
* Max Rope Diameter: 12 mm
* Safe Working Load (SWL): 1000 kg
* Breaking Load (BL): 2000 kg
* Weight: 24 g
* Flange Diameter (D): 44 mm
* Height (H): 31 mm
* Required Hole Diameter: 22 mm

Choose the ROPEYE TDP 12 Bushing for your vessel and invest in a lighter, faster, and more reliable sailing experience. It is the definitive choice for sailors who refuse to compromise on quality and performance
