E-t-a GS11466 Push Botton

E-T-A GS11466 Push Button Thermal Circuit Breaker

Protect your valuable electronic and electrical equipment with the superior performance of the E-T-A GS11466 Push Button Circuit Breaker. Engineered for reliability and safety, this device offers a robust and reusable alternative to traditional single-use fuses, safeguarding your systems against damage from overcurrent and short circuits. Ideal for a wide range of applications in the electronics and electrical connections sector, from power supplies and industrial control panels to medical devices and household appliances, the GS11466 ensures your operations continue with minimal downtime.

This component is a single pole thermal circuit breaker with a push-to-reset tease-free, trip-free, snap action mechanism. Its intelligent design provides an unparalleled level of safety; the trip-free feature guarantees that the circuit will remain open in the event of an overload, even if the reset button is manually held in the on position. This prevents accidental resets into a fault condition, protecting both the user and the equipment. The snap-action mechanism ensures a quick and decisive break of the circuit, minimizing the risk of electrical arcing and enhancing the device´s longevity and reliability.

Key Benefits:

* Enhanced Equipment Protection: Provides precise and dependable thermal overcurrent protection, preventing costly damage to sensitive components and extending the life of your machinery.
* Cost-Effective and Reusable: Unlike one-time-use fuses, this circuit breaker can be easily reset after tripping. This reduces maintenance costs, eliminates the need for replacement inventory, and significantly shortens system downtime.
* Uncompromised Safety: The trip-free and tease-free design ensures the circuit cannot be held closed during a fault condition, offering a superior level of operational safety for all users.
* Effortless Installation: Designed with a convenient threadneck for panel mounting, allowing for quick, secure, and clean integration into control panels, dashboards, and equipment housings.
* Clear Status Indication: The push button extends to a visible off position upon tripping, providing an immediate and clear visual indication of a circuit fault, simplifying troubleshooting.

Main Features:

* Single Pole Thermal Overcurrent Protection
* User-Friendly Push-to-Reset Operation
* Advanced Trip-Free and Tease-Free Mechanism
* Reliable, High-Performance Snap Action Switching
* Secure Threadneck Design for Panel Mounting
* Compact and Durable Construction
* Internationally Approved for Global Compliance (UL, CSA, VDE)

Buttons:

The central feature of this device is its integrated Push Button. This dual-function button serves as the manual reset actuator following an overcurrent trip. When the circuit is live and operational, the button sits flush with its housing. Upon tripping, the button pops out, providing a clear tactile and visual signal that the circuit has been interrupted. A simple push resets the device, restoring power once the fault condition has been cleared.

Technical Specifications:

* Product: E-T-A GS11466 Push Button Circuit Breaker
* Category: Electronics
* Subcategory: Electrical Connections
* Electricity: 6 A
* Voltage Rating: Up to 250 V AC; 28 V DC
* Mechanism: Single Pole, Thermal, Push-to-Reset
* Mounting: M12 Threadneck Panel Mount
* Typical Life: 5.000 cycles at rated current
* Approvals: Conforms to UL 1077, CSA C22.2 No. 235, VDE, EN 60934 (IEC 60934)
* Ambient Operating Temperature: -20°C to +60°C (-4°F to 140°F)
