Blue Sea Systems AC Toggle Source Selector 230V/Panel 16A

BLUE SEA SYSTEMS AC Toggle Source Selector 230V/Panel 16A

Effortlessly and safely manage your vessel´s or vehicle´s onboard AC power with the Blue Sea Systems AC Toggle Source Selector Panel. Designed specifically for European 230V systems, this robust panel provides a reliable and intuitive solution for switching between two separate AC power sources, such as shore power and a generator or inverter. Eliminate the complexity and potential hazards of managing multiple power inputs with a single, centralized control point engineered for the demanding marine environment.

This source selector panel is built around the core principle of safety. Its most critical benefit is the prevention of dangerous and damaging out-of-phase connections. The intuitive design ensures that you can never accidentally connect both shore power and your secondary source simultaneously, protecting your sensitive electronics, wiring, and even utility line workers from hazardous back-feeding. With clear visual indicators and robust circuit protection, you gain complete peace of mind, knowing your electrical system is managed correctly and securely.

Key Benefits:

* Uncompromised Safety: The integrated mechanical lockout slide physically prevents the simultaneous connection of two AC sources, eliminating the risk of catastrophic damage and ensuring the safety of personnel and equipment.
* Complete System Protection: Equipped with a high-quality 16A double pole main circuit breaker, this panel provides essential overcurrent protection for your entire AC system, tripping both the live and neutral lines as required for 230V applications.
* Clear, At-a-Glance Status: Brightly lit LEDs provide immediate visual confirmation of system status. Green LEDs indicate when power is available from either source, while a red reverse polarity indicator warns of potentially hazardous wiring issues before any equipment is energized.
* Simplified Operation: A single, heavy-duty toggle switch makes selecting your desired power source straightforward and foolproof. The intuitive layout reduces user error and simplifies power management for everyone on board.
* Marine-Grade Durability: Constructed to withstand the harsh conditions of the marine environment, this panel is built for longevity and reliability when you need it most.

Main Features:

AC Toggle Source Selector .

Double pole AC main circuit breakers with installed lockout slide.

Prevents connecting both AC sources simultaneously.

Maximum panel amperage - 50 Amperes.
* Green "Power Available" indicator LEDs for Source 1 and Source 2
* Red "Reverse Polarity" warning indicator LED
* Includes a comprehensive set of pre-printed labels for easy circuit identification

Panels

The Blue Sea Systems panel is engineered for durability and seamless integration. It is constructed from heavy-duty 1/8" 5052 aluminum alloy, which is then chemically treated and finished with a slate gray polyurethane coating. This multi-stage process provides superior corrosion resistance and a clean, professional aesthetic that complements any helm or electrical cabinet. The panel features backlit label positions, allowing for easy viewing and operation in low-light or nighttime conditions (backlighting kit sold separately). Its compact and efficient design ensures it can be installed easily into tight spaces without sacrificing functionality or accessibility.

Technical Specifications
* Panel Type: AC Main Source Selector
* Positions: 2 (Source 1 / OFF / Source 2)
* Nominal Voltage: 230V AC
* Circuit Breaker Rating: 16 Amperes
* Breaker Type: Double Pole (Switches both Live and Neutral)
* Maximum Panel Amperage: 50A
* Height: 5.25" (133.35 mm)
* Width: 3.75" (95.25 mm)
* Depth: 4.00" (101.6 mm)
* Regulatory: CE marked for compliance with European standards; meets ABYC (American Boat and Yacht Council) requirements
