Marinco Battery Selector Switch 230A

MARINCO 230A Battery Selector Switch | Ultimate Control for Marine & RV Electrical Systems

Ensure your vessel or vehicle always has the power it needs with the robust and reliable MARINCO Battery Selector Switch. Engineered for demanding marine and automotive environments, this essential component from the Electronics category provides complete and intuitive control over your dual battery setup. Eliminate the risk of a dead starting battery and manage your power resources with confidence, whether you are out on the water, on the road in your RV, or operating a heavy-duty service vehicle. This switch is the cornerstone of a safe and efficient electrical system, offering peace of mind and unparalleled performance.

Key Benefits:

* Complete Power Management: Effortlessly switch between two independent battery banks. Isolate your starting battery to preserve its charge while using your house battery for accessories, or select the house battery for starting if needed.
* Emergency Starting Power: The "1+2" position combines the power of both battery banks, providing a crucial boost for engine starting in emergency situations or cold weather.
* Uninterrupted Operation: Featuring "make-before-break" contact design, this switch allows you to switch between battery banks while the engine is running without causing damaging voltage spikes or interrupting power to sensitive electronics.
* Superior Durability: Built to withstand the harshest conditions, its rugged construction ensures long-lasting service life, protecting your investment and guaranteeing performance when you need it most.
* Enhanced Safety: Ignition-protected and sealed against the elements, it is certified safe for installation in gasoline engine compartments and exposed locations, preventing accidental sparks and resisting water intrusion.

Main Features

This selector switch is designed with both performance and ease of use in mind. The universal mount switches have longer stud lengths for improved assembly and easier cable routing, simplifying installation even in tight spaces. They are built with heavy-duty copper sweep contacts to ensure positive circuit control, delivering maximum conductivity with minimal voltage drop.

Rugged internal components are protected by a tough, impact resistant polycarbonate housing that is impervious to the elements, safeguarding the switch against moisture, salt spray, and UV degradation. The tactile and ergonomic selector knob provides clear, positive detents for each position, so you can be certain of your selection even without looking.

Switches and Technical Specifications
* Product Type: Battery Selector Switch
* Category: Electronics
* Subcategory: Electrical connections
* Continuous Amperage Rating: 230A DC
* Intermittent Amperage Rating: 350A DC (up to 5 minutes)
* Cranking Amperage Rating: 1000A DC (up to 10 seconds)
* Maximum Voltage: 48V DC
* Switch Positions: 4 (Battery 1 / Battery 2 / Battery 1+2 / OFF)
* Terminal Stud Material: Tinned Copper for superior conductivity and corrosion resistance
* Terminal Stud Size: 3/8" - 16 (M10)
* Mounting Options: Versatile design allows for both surface mount and rear panel mounting
* Housing Material: High-impact, UV-stabilized Polycarbonate
* Safety Certification: Ignition Protected to meet SAE J1171 and ISO 8846 marine standards
* Ingress Protection: Rated to IP66, signifying protection against powerful water jets and dust ingress

Choose the MARINCO 230A Battery Selector Switch for uncompromising quality and precise control over your critical electrical systems. It´s the ideal solution for any boat, yacht, RV, or utility vehicle requiring a dependable dual battery management system
