Samlex Link Lite Battery controller 64 mm

Samlex LinkLite Battery Monitor Controller | 64mm Precision Display

Category: Electronics
Subcategory: Instruments

Gain complete and accurate insight into your battery system with the Samlex LinkLite Battery Controller. This advanced battery monitor is an essential instrument for any serious off-grid, marine, or recreational vehicle power system. Eliminate the guesswork and uncertainty associated with battery voltage as a state-of-charge indicator. The LinkLite provides a precise, real-time "fuel gauge" for your battery bank, allowing you to manage your power consumption effectively, prevent unexpected shutdowns, and significantly extend the life of your expensive batteries.

Designed for clarity and ease of use, the LinkLite features a large, clear LCD screen housed in a standard 64 mm round body, making it simple to install and integrate into any dashboard or control panel. This sophisticated controller continuously tracks the flow of energy in and out of your battery, providing you with critical data at a glance. By understanding your true power usage and remaining capacity, you can make informed decisions, ensuring you have reliable power when you need it most.

Key Benefits:

* Prevent Costly Battery Damage: By monitoring the true State of Charge (SoC) and setting a low-battery alarm, you can avoid deep discharges that permanently damage and reduce the lifespan of your battery bank.
* Total Power Awareness: Move beyond simple voltage readings. The LinkLite accurately displays the remaining battery capacity in Amp-hours (Ah) and as a percentage (%), giving you a reliable fuel gauge for your electrical system.
* Optimize Your Energy Usage: See exactly how much current your appliances and devices are drawing in real-time. This invaluable information helps you manage consumption, identify power-hungry devices, and optimize your system´s efficiency.
* Historical Performance Data: The device stores crucial historical data, such as the deepest discharge, average discharge, and the number of charge/discharge cycles. This allows you to analyze your battery´s long-term health and performance.

Main Features:

* Displays real-time battery voltage (V), current (A), consumed Amp-hours (Ah), and State of Charge (SoC %).
* Large, high-contrast liquid crystal display (LCD) for excellent readability.
* Compact, standard 64 mm (2.5") round instrument housing for easy mounting.
* A fully programmable visual and audible alarm to signal low battery state.
* Two-battery input capability for monitoring a starter and a service battery.
* Stores a wide range of historical battery data for performance analysis.
* Splash-proof front panel suitable for marine and vehicle environments.
* Includes a high-precision 500 Amp shunt for accurate current measurement.

Technical Specifications:

* Attribute: Controllers
* Input Voltage Range: 9 - 35 VDC
* Battery Capacity Range: 20 - 9999 Ah
* Current Measurement Range (with 500A Shunt): +/- 0 - 500 A
* Current Measurement Resolution: 0.1 A (<100 A), 1 A (>100 A)
* Shunt Specification: 500 A / 50 mV
* Display: High Contrast LCD
* Dimensions (Front Bezel): 64 mm diameter
* Dimensions (Body): 52 mm diameter
* Mounting: Standard 52 mm (2") instrument cutout
* Alarm: Visual (flashing display) and Audible (internal buzzer)
* Power Consumption (Backlight Off): 4 mA @ 12V
* Power Consumption (Backlight On): 15 mA @ 12V
