Ultraflex B184 Simple Lever Engine Control

ULTRAFLEX B184 Simple Lever Engine Control: Precision Dual Action Control for Any Boat

Elevate your command and experience unparalleled control at the helm with the ULTRAFLEX B184 Simple Lever Engine Control. Engineered for precision, reliability, and outstanding versatility, this engine control system is the perfect upgrade for any boater seeking smoother operation and enhanced safety on the water. Designed to integrate seamlessly into a wide variety of vessels, the B184 provides a robust and intuitive connection between you and your engine, ensuring every journey is managed with confidence. Its sleek yet rugged design is built to withstand the rigors of the marine environment, offering you years of dependable service.

The B184 is a testament to superior marine engineering, offering a single-lever, dual-action solution that manages both throttle and gearbox functions effortlessly. This streamlined operation simplifies maneuvering, docking, and cruising, allowing you to focus more on the enjoyment of being on the water. Whether you are navigating tight marina spaces or adjusting for the perfect trolling speed, the B184 delivers the responsiveness and accuracy you demand.

Key Benefits of the ULTRAFLEX B184
* Unmatched Installation Flexibility: The B184 can be top-mounted or side-mounted to fit your helm´s specific layout. Its innovative design allows for installation on either the port or starboard side, in both horizontal and vertical orientations, providing a custom fit for virtually any cockpit configuration.
* Intuitive and Safe Operation: Experience effortless engine warm-ups by simply pulling out the hand levers, disengaging the gearbox. For enhanced safety, the B184 is compatible with an optional X12 safety switch, which prevents the engine from starting unless the gearbox is securely in the neutral position.
* Precision and Stability: A built-in, adjustable friction drag mechanism prevents throttle creep caused by engine vibration or rough seas. This ensures your set speed remains constant, improving fuel efficiency and reducing the need for constant adjustments. A lever lock device further enhances security.
* Durable, Marine-Grade Design: The hub and lever are constructed from high-quality die-cast aluminium and finished with a protective varnish. This robust build provides exceptional durability and superior resistance to corrosion, ensuring a long and reliable service life in harsh saltwater and freshwater environments.

Levers

The ULTRAFLEX B184 features ergonomic, dual-action hand levers that provide integrated control of both the throttle and gearbox. The levers are designed for a comfortable grip and feature a simple pull-out mechanism for neutral engine warm-up. The primary lever includes a built-in, thumb-operated power trim and tilt switch for effortless on-the-fly adjustments.

Technical Specifications
* Control Type: Dual action (throttle and shift in one lever)
* Mounting Style: Top Mount / Side Mount
* Installation Orientation: Port or Starboard, Horizontal or Vertical
* Key Features: Integrated trim switch, lever lock device, built-in friction drag, neutral warm-up function
* Application: Suitable for outboard, inboard, and stern-drive engines with hydraulic gearboxes
* Cable Compatibility: Designed for use with all ULTRAFLEX control cables except C4, C36, and MACH36.
* Standard Cables: Directly compatible with C2, C8, C14, MACH0, and MACH14 cables.
* Adapter Requirement: ULTRAFLEX C5, C16, and MACH5 cables require the K35 Adapter Kit (Art. 4242069) for proper installation
